RYTEC System 3 User Manual

16
SYSTEM STARTUP—PARAMETERS
Service Level 1 Parameters
Table 2 below lists the parameters available through
Service Level 1. Included in this table is a description of
each parameter, and its available range and factory
default setting.
Table 2
Parameter Range Service Level 1 Parameters (Password = 5) Factory
Setting
P. 0 00 Door cycle counter (read only)
P. 0 10 0 – 200 seconds Auto-close delay timer 1 – ACL1 (with activator connected to
input 5 – terminal 14)
0 = off
10
P. 0 11 0 – 200 seconds Auto-close delay timer 3 – ACL3 (used with optional passage
position only)
0 = off
0
P. 0 15 0 – 200 seconds Auto-close delay timer 2 – ACL2 (with activator connected to
input 6 – terminal 16 or input 7 – terminal 18)
0 = off
5
P.050
(Defrost
System Only)
0 – 3 Heater status
0: off
1: on – low heat stage 1 heated blower or heat lamps
2: on – medium heat stage 1 + 2 heated blower
3: on – high heat stage 1 + 2 + 3 heated blower
0
P.051
(Defrost
System Only)
0 – 1 Heater control (parameter 050 must be set to on)
0: manual
1: automatic timer
0
P.055
(Defrost
System Only)
0 – 3 Blower control
0: off
1: low-speed
2: high-speed
3: automatic (blower runs at high speed when door is open)
0
P.058
(Defrost
System Only)
5 – 600 minutes Heater timer on time 30
P.059
(Defrost
System Only)
5 – 600 minutes Heater timer off time 5
P. 2 10 0 – 5 Limit Setup
0: off
1: open, close, and partial setup (partial set using P.244)
2: open
3: open and close
4: partial (P.244 ignored)
5: all (partial set using P.244)
0
P. 2 21 ±125 increments Close limit adjustment
(For minor adjustments to the close position of the door. This
adjustment resets to 0 if the limits are reset.)
0
