SPECIFICATIONS—MECHANICAL
SPECIFICATIONS
MECHANICAL
INPUTS
Enclosure Standard steel box, painted, with window
WxHxD (without mounting feet):
Standard version
14.95 in. x 23.62 in. x 8.27 in.
•Freezer version
23.62 in. x 23.62 in. x 8.27 in.
Installation Four mounting feet (max. 0.4 in. high)
Weight Type-A and -B: 58 lb. approximately
Type-C: 75 lb. approximately
Protection Class: NEMA Type 4
Operating Temperature Range 14°F — 149°F
Wiring Entries Removable knockout plate on bottom of enclosure
Power Supply (Line Voltage) Standard 230 volt:
180 — 253 V, 50 — 60 Hz, 3-phase
Standard 460 volt:
360 — 506 V, 50 — 60 Hz, 3-phase
Freezer:
360 — 506 V, 50 — 60 Hz, 3-phase
115 V, 50 — 60 Hz, single-phase
Emergency Input
(E-Stop 1 and E-Stop 2)
For dry contacts only (normally closed):
Maximum load — 26 V / 200 mA
Input level < 5 V, input ON
Input level > 7 V, input OFF
Both inputs indicated by LED, ON at 24 V
Inputs IN1 — IN12 (Standard Inputs) For dry contacts or 24-V active PNP outputs:
Maximum load — 26 V / 200 mA DC only
Input level > 8 V, input ON
Input level < 5 V, input OFF
N/O functions:
Input level < 5 V, input ON
Input level > 8 V, input OFF
N/C functions:
Some programmable
Each input indicated by LED, ON at 24 V
Inputs SSI-Data A and B (Interface
Pos.):
Output SSI-Clock A and B
For absolute encoder
Input for Safety Edge Usable for N/O contacts of safety edge with 1.2 k-ohm resistor
Inputs for Induction Loops (floor
loops)
Usable with optional in-floor wiring for loop detector plug-in module
