26
SYSTEM STARTUP—FAULT CODES
FAULT CODES
General Operation Fault Codes
Table 4 below lists possible fault codes associated with
the general operation of the door. Included in this table
is a description of each fault code and the suggested,
corrective action. (Door is in the error jog only mode.)
Table 4
Fault Code
(Door Status)
Description Corrective Action
F.0 00 Door opens beyond full-open position.
1. motor brake faulty or improperly adjusted
2. position parameters incorrect for this
door
1. repair or adjust motor brake
2. consult factory
F.0 05 Door closes beyond full-closed position.
1. motor brake faulty or improperly adjusted
2. position parameters incorrect for this
door
1. repair or adjust motor brake
2. consult factory
F.0 20 Door open run time exceeded.
1. blocked door
2. sluggish motor
3. run time set too low
1. check mechanical operation of door
2. check motor
3. consult factory
F.0 30 Door travel incomplete.
1. blocked door
2. jammed motor
3. encoder incorrectly installed
4. encoder problem
5. low start torque or speed
1. check mechanical operation of door
2. check motor and brake
3. check encoder mounting
4. check encoder operation
5. consult factory
F.0 31 Door moves in wrong direction.
1. encoder wired incorrectly
2. motor running in wrong direction
3. motor brake releases early
1. check encoder and encoder connec-
tions. Adjust motor operating frequency
(P.185) or brake release timing (P.186).
2. check motor rotation
3. consult factory
F.0 43 Photo eye deactivation position problem. Check encoder operation.
F.0 50 Does not apply. Consult factory.
F.0 60 Bottom bar breakaway input activated. Reassemble bottom bar or repair break-
away switch.
F.0 70 Door panel closed beyond cleaning
position.
1. motor brake faulty or improperly adjusted
2. position parameters incorrect for this
door
Adjust cleaning position (P.070).
1. repair or adjust motor brake
2. consult factory
