SYSTEM STARTUP—FAULT CODES
Door Position Fault Codes
Table 9 below lists possible fault codes associated with
the position of the door. Included in this table is a
description of each fault code and the suggested, cor-
rective action.
Table 9
F.5 30 Excessive heat sink temperature.
1. ambient air temperature above or below
acceptable operating range
2. door operating problems
1. adjust ambient air temperature as
required
2. check operation of door
F.5 40 Excessive brake resistor temperature.
1. ambient air temperature above or below
acceptable operating range
2. door operating problems
1. adjust ambient air temperature as
required
2. check operation of door
Fault Code
(Drive System)
Description Corrective Action
Fault Code
(Door Position)
Description Corrective Action
F.7 00 Door limits not set.
1. set limits
2. possible encoder failure
1. set limit P.210
2. check encoder
F.7 20 Door limits not set.
1. limits not adjusted
2. possible encoder failure
3. door travel problem
1. set limits
2. check encoder
3. See F.030 and F.031
F.7 50 Data transmission error.
1. possible electromagnetic interference
(EMI) to control system
2. encoder problem
1. shielded cable broken, no longer
grounded, or not used where required
2. check encoder
F.7 51 Data transmission error.
1. possible electromagnetic interference
(EMI) to control system
2. encoder problem
1. shielded cable broken, no longer
grounded, or not used where required
2. check encoder
F.7 52 Data transmission error.
1. possible electromagnetic interference
(EMI) to control system
2. encoder problem
1. shielded cable broken, no longer
grounded, or not used where required
2. check encoder
F.7 60 Position of door does not correspond to
position of encoder.
1. possible electromagnetic interference
(EMI) to control system
2. encoder or encoder mounting problem
3. incorrect resolution setting
1. shielded cable broken, no longer
grounded, or not used where required
2. check encoder
3. consult factory
F.7 61 Does not apply. Consult factory.
