35
SPECIFICATIONS—OPTIONAL PLUG-IN MODULES
OPTIONAL PLUG-IN MODULES
OPTIONAL 24-VAC TRANSFORMER
(STANDARD CONTROL PANEL ONLY)
Expansion Board Included in freezer version, optional for standard versions
Electronic board with plug-in terminal strips
Master switch
Relay outputs (total of five):
Common in groups of two and three relays
•Programmable
N/O / N/C, dry contacts
Switching current — 10 mA — 3 A AC / DC
Contact rating — Pilot Duty B300
If contacts were used for high current (>100 mA)
switching, do not use for low current switching.
Inputs (total of eight):
For dry contacts or 24-V active PNP outputs
Maximum load — 26 V / 200 mA
Input level > 7 V, input ON
Input level < 5 V, input OFF
N/O functions
•Programmable
Interlock inputs (total of four):
48 VAC / 24 VDC
Maximum 3 A
Radio Receiver 2-channel receiver, 433 MHz
Loop Detector 1-channel detector or 2-channel detector
Supply (Primary Side) 1-phase, 230/400/460/520 ± 20 VAC
Internally protected by two 1 A, class CC fuse
Secondary Side 24 V, 50—60 Hz
Maximum load — 5.5 A
Internally protected by one 6 A, class CC fuse
