s::can con::cube D-330 - 12 Technical Specifications

12 TechnicalSpecications
Name Specication Remark
Part-no. D-330-230
D-330-024
con::cube with AC power supply
con::cube with DC power supply
Dimensions housing 280 / 209 / 85 mm W / H / D
Required space 290 / 280 / 240 mm W / H / D
Weight approx. 4 kg
Operation temperature -20 to 50°C (-4 to 122°F) at max. temperature sun shield
recommended
Storage temperature -20 to 60°C (-4 to 140°F) Acclimatised device to operation
temperature before initial operation.
Humidity 5 to 90% non-condensing
Material housing Aluminium alloy, powder coated
Environment rating (IP) IP 65 see section 4.1
Environmental conditions Altitude up to 2000 m
Overvoltage category II
Pollution degree 2
Mounting 4 x M5 thread holes on backside
2 mounting brackets and 4 screws
(included in delivery)
for direct mounting on panels (F-501)
for wall mounting from front side
Power supply D-330-024 10 to 36 VDC
Power supply D-330-230 100 to 240 VAC / 50 to 60 Hz wide range power supply unit
Power supply cable outside diameter 5 - 12 mm
single cable wires 1.5 - 2.5 mm
2
min. 80°C
min. 300 VAC
Required galvanic isolation of power
input
3.0 kV
1.5 kV
D-330-230
D-330-024
Power consumption 1.5 W (typical)
10 W (typical) / 20 W (max.)
30 W (typical) / 60 W (max.)
in sleep mode
no I/O ports
fully equipped
Electric potential Grounding
for D-330-024 and D-330-230
max. 0.1 Ohm PE power supply to
site‘searthgrounding
max. 0.5 Ohm PE power supply to
process medium; see section 5.5
Conformity - ECM EN 61326-1
Conformity - safety EN 61010-1
UL 61010-1:2004 R10.08
CAN/CSA-C22.2 NO.
61010-1-04+GI1 (R2009)
Fuse internal replacement by s::can Service only
Internal battery CR2032, 3V Lithium battery for real time clock (RTC)
Connection of
s::can spectrometer probe
1 x M12 (IP 67, RS485, 12 VDC)
galvanically isolated 1 kV
internal network termination 120 Ohm
Connection of s::can ISE probes or
s::can sensors
4 x sys plug connector
(IP 67, RS485, 12 VDC)
galvanically isolated 1 kV
internal network termination 120 Ohm
