s::can con::cube D-330 - 11 Accessories; 11.1 Installation; 11.1.1 Weather Shield; 11.1.2 Power Supply Cord

11 Accessories
11.1 Installation
11.1.1 Weather Shield
For protection of the con::cube in case of outdoor installation and for easy mounting on walls
orrailingsaspecichousingisavailable.
Name Specication Remark
Part-no. F-51
Housing material stainless steel (1.4301)
Dimensions 363 / 553 / 170 mm W / H / D
Weight 5 kg
Mounting bracket 2 x M8 U-bolt with screw nut
and spring washer
4xM5angenut
included in delivery for
mounting onto rails
11.1.2 Power Supply Cord
For connection of the device to the power supply, a power supply cable is available.
Name Specication Remark
Part-no. C-31-EU or C-31-US
Cable length 2 m
Weight approx. 300 g
Material PU jacket
Process connection CEE-7 shockproof plug
NEMA 5-15 plug
C-31-EU
C-31-US
Environment rating (IP) IP 44
IP 55
C-31-EU
C-31-US
