7.5 DataTransferviaProbusDPInterface
TheProbus DPoutputmodule (D-315-OUT-PROFIBUS)providesaProbusDPcompatibleeldbus interface(according
toIEC61158)fortheintegrationofthecon::cubeintoProbusDPnetworks.ProbusDPsupportsupto244Bytesofoutput
data. This enables the transfer of readings and status information for up to eight parameters as well as the system status. The
location and type of the values are shown in the table below.
ProbusPosition Data Type Name Description
0x02 – 0x03 Bitmask bmDeviceStatus System status of con::cube
0x04 – 0x05 Bitmask bmP1Status Status of parameter 1
0x06 – 0x09 Float xP1Value Reading of parameter 1
0x0A – 0x0B Bitmask bmP2Status Status of parameter 2
0x0C – 0x0F Float xP2Value Reading of parameter 2
0x10 – 0x11 Bitmask bmP3Status Status of parameter 3
0x12 – 0x15 Float xP3Value Reading of parameter 3
0x16 – 0x17 Bitmask bmP4Status Status of parameter 4
0x18 – 0x1B Float xP4Value Reading of parameter 4
0x1C – 0x1D Bitmask bmP5Status Status of parameter 5
0x1E – 0x21 Float xP5Value Reading of parameter 5
0x22 – 0x23 Bitmask bmP6Status Status of parameter 6
0x24 – 0x27 Float xP6Value Reading of parameter 6
0x28 – 0x29 Bitmask bmP7Status Status of parameter 7
0x2A – 0x2D Float xP7Value Reading of parameter 7
0x2E – 0x2F Bitmask bmP8Status Status of parameter 8
0x30 – 0x33 Float xP8Value Reading of parameter 8
0x34 – 0x40 TAI64n tSampleTime Time of last measurement
7.6 Data Transfer via SDI12 Interface
TheSDI12module(D-315-OUT-SDI12)providesaSDI12compatibleeldbusinterfacefortheintegrationofthecon::cubeinto
SDI12 networks. The module enables the transfer of readings and status information for up to eight parameters as well as the
system status. The location and type of the values are shown in the table in section 7.5.
Parameter readings can be queried via a SDI12-Master connected to the con::cube using a simple terminal programm (e.g.
Docklight). For reading of measurement results the following commands are needed (ASCII-code):
Action Command Description
Send 0M!<CR><LF> Start measurement parameter 1
Answer 00001<CR><LF>
Send 0D!<CR><LF> Query of measurement result
Answer Measurement result of parameter 1
Send 0M1!<CR><LF> Start measurement parameter 2
Answer 00001<CR><LF>
Send 0D!<CR><LF> Query of measurement result
Answer Measurement result of parameter 2
...
Send 0M7!<CR><LF> Start measurement parameter 8
Answer 00001<CR><LF>
Send 0D!<CR><LF> Query of measurement result
Answer Measurement result of parameter 8
<CR> ..... Carriage Return
<LF> ..... Line feed
