11.4 Optional Features
The con::cube can be equipped with several optional features explained in the sections below. Regarding detailed information
oftheoptionalfeaturespleaserefertothetechnicalspecicationslocatedattheendofthismanual.
11.4.1 Gateway to 3G Modem
This optional available internal module provides wireless remote control and / or data transfer. The modem should be ordered
atthesametimeasthecon::cubebecauselatermodicationisnotpossiblebycustomerhimself.
Name Specication Remark
Part-no. D-315-3G
Assembling ex factory
Optional features D-315-ANTENNA-PLUG
D-315-ANTENNA-PRO
11.4.2 Analog Output Module
This optional module provides two analog outputs for data transfer to PLC systems.
Name Specication Remark
Part-no. D-315-OUT-MA
Output 2 x 4 - 20 mA
Interface AWG 28-12,
stripped wire
via terminal block, see sec-
tion 5.1 for correct wiring
Conguration via moni::tool software see section 12.1 for address
mapping
Assembling onlybyqualiedpersonal
authorized by s::can
con::cube can be equipped
with max. 8 modules
11.4.3 Digital Output Module
Thisoptionalmoduleprovidesfourcongurablerelayoutputsfortriggeringfunctions.
Name Specication Remark
Part-no. D-315-OUT-RELAY
Output 4 x digital out
Interface AWG 28-12,
stripped wire
via terminal block, see sec-
tion 5.1 for correct wiring
Conguration via moni::tool software
11.4.4 ProbusDPOutputModule
ThisoptionalmoduleprovidesProbusDPaninterfacefordatatransfertoPLCsystems.
Name Specication Remark
Part-no. D-315-OUT-PROFIBUS
Output ProbusDP
Interface Sub-D9, IP 67 via terminal block, see sec-
tion 5.1 for correct wiring
Conguration via moni::tool software see section 12.2
Assembling onlybyqualiedpersonal
authorized by s::can
con::cube can be equipped
with 1 module at slot no. 8
