M a p p i n g o f P a r a m e t e r s p e c i f i c H o l d i n g R e g i s t e r
Holding register,
16bit, RW
Tag name Address Type Length R/W Description Address
parameter 1 result bmP1Status 0x1020 bitmask 1 R Para.1 status
1)
4128
xP1Value 0x1022 oat 2 R Para.1 result 4130
parameter 2 result bmP2Status 0x1028 bitmask 1 R Para.2 status
1)
4136
xP2Value 0x102A oat 2 R Para.2 result 4138
parameter 3 result bmP3Status 0x1030 bitmask 1 R Para.3 status
1)
4144
xP3Value 0x1032 oat 2 R Para.3 result 4146
......
parameter 32 result bmP32Status 0x1118 bitmask 1 R Para.32 status
1)
4376
xP32Value 0x111A oat 2 R Para.32 result 4378
The representation of the system / device / parameter status and denotation of the single bits (b
0
... b
15
) is shown in the tables
below. Bits that are not represented in the tables are not supported or reserved.
Each bit reperesents a condition (1=error, 0=o.k.)
M a p p i n g o f P a r a m e t e r S t a t u s ( b m P x S t a t u s )
Bit Display (xPxValue) Status Description
b0 NaN or value General parameter
error
At least one internal parameter check failed.
For details check all other status bits.
Unknown failure if all other status bits are ok.
b11 value Maintenance
necessary
vali::tool recommends check of system
integrity (functional check).
Ifsystemintegrityisok,vali::toolconguration
needs to be adapted.
b13 value Parameter alarm ana::tool / alarm parameter reports parameter
alarm
b14 value Parameter warning ana::tool / alarm parameter reports parameter
warning
M a p p i n g o f S y s t e m S t a t u s ( b m D e v i c e S t a t u s )
Bit Display (xPxValue) Status Description
b0 NaN General device error Communication to connected devices failed.
Probe or sensor misuse.
Probe or sensor malfunction or failure.
