M a p p i n g o f P a r a m e t e r s p e c i f i c I n p u t R e g i s t e r
Input register, 16bit, RO Tag name Address Type Length R/W Description Address
parameter 21 result bmP21Status 0x0120 bitmask 1 R Para.21 status
1)
288
xP21Value 0x0122 oat 2 R Para.21 result 290
parameter 22 result bmP22Status 0x0128 bitmask 1 R Para.22 status
1)
296
xP22Value 0x012A oat 2 R Para.22 result 298
parameter 23 result bmP23Status 0x0130 bitmask 1 R Para.23 status
1)
304
xP23Value 0x0132 oat 2 R Para.23 result 306
parameter 24 result bmP24Status 0x0138 bitmask 1 R Para.24 status
1)
312
xP24Value 0x013A oat 2 R Para.24 result 314
parameter 25 result bmP25Status 0x0140 bitmask 1 R Para.25 status
1)
320
xP25Value 0x0142 oat 2 R Para.25 result 322
parameter 26 result bmP26Status 0x0148 bitmask 1 R Para.26 status
1)
328
xP26Value 0x014A oat 2 R Para.26 result 330
parameter 27 result bmP27Status 0x0150 bitmask 1 R Para.27 status
1)
336
xP27Value 0x0152 oat 2 R Para.27 result 338
parameter 28 result bmP28Status 0x0158 bitmask 1 R Para.28 status
1)
344
xP28Value 0x015A oat 2 R Para.28 result 346
parameter 29 result bmP29Status 0x0160 bitmask 1 R Para.29 status
1)
352
xP29Value 0x0162 oat 2 R Para.29result 354
parameter 30 result bmP30Status 0x0168 bitmask 1 R Para.30 status
1)
360
xP30Value 0x016A oat 2 R Para.30 result 362
parameter 31 result bmP31Status 0x0170 bitmask 1 R Para.31 status
1)
368
xP31Value 0x0172 oat 2 R Para.131 result 370
parameter 32 result bmP32Status 0x0178 bitmask 1 R Para.32 status
1)
376
xP32Value 0x017A oat 2 R Para.32 result 378
1)
Please refer to table Mapping of Parameter Status
M a p p i n g o f D e v i c e s p e c i f i c H o l d i n g R e g i s t e r
Holding register,
16bit, RO
Tag name Address Type Length R/W Description Address
device
description
uiVersion 0x0FA0 unit16 1 R Version of Modbus mapping
protocol. For all changes in public
registers: 0xAABB
AA ... Major version
BB ... Minor version (compatible)
4000
eVendor 0x0FA1 enum 1 R Vendor code 4001
eModel 0x0FA2 enum 1 R Device model 4002
abModel 0x0FA3 char[20] 10 R Description of device model,
lledwithspaces
4003
abSerialNumber 0x0FAD char[8] 4 R Serial number,
lledwithspaces
4013
abSWRelease 0x0FB3 char[4] 2 R Software release: 0xAABB
AA ... Major version
BB ... Minor version
4019
device status
public
tSampleTime 0x0068 timestamp 6 R Time when the parameter results
have been updated. Timestamp of
logged status and results
4104
bmDeviceStatus 0x0078 bitmask 1 R Device status 4120
