M a p p i n g o f P a r a m e t e r s p e c i f i c I n p u t R e g i s t e r
Input register, 16bit, RO Tag name Address Type Length R/W Description Address
parameter 1 result bmP1Status 0x0080 bitmask 1 R Para.1 status
1)
128
xP1Value 0x0082 oat 2 R Para.1 result 130
parameter 2 result bmP2Status 0x0088 bitmask 1 R Para.2 status
1)
136
xP2Value 0x008A oat 2 R Para.2 result 138
parameter 3 result bmP3Status 0x0090 bitmask 1 R Para.3 status
1)
144
xP3Value 0x0092 oat 2 R Para.3 result 146
parameter 4 result bmP4Status 0x0098 bitmask 1 R Para.4 status
1)
152
xP4Value 0x009A oat 2 R Para.4 result 154
parameter 5 result bmP5Status 0x00A0 bitmask 1 R Para.5 status
1)
160
xP5Value 0x00A2 oat 2 R Para.5 result 162
parameter 6 result bmP6Status 0x00A8 bitmask 1 R Para.6 status
1)
168
xP6Value 0x00AA oat 2 R Para.6 result 170
parameter 7 result bmP7Status 0x00B0 bitmask 1 R Para.7 status
1)
176
xP7Value 0x00B2 oat 2 R Para.7 result 178
parameter 8 result bmP8Status 0x00B8 bitmask 1 R Para.8 status
1)
184
xP8Value 0x00BA oat 2 R Para.8 result 186
parameter 9 result bmP9Status 0x00C0 bitmask 1 R Para.9 status
1)
192
xP9Value 0x00C2 oat 2 R Para.9 result 194
parameter 10 result bmP10Status 0x00C8 bitmask 1 R Para.10 status
1)
200
xP10Value 0x00CA oat 2 R Para.10 result 202
parameter 11 result bmP11Status 0x00D0 bitmask 1 R Para.11 status
1)
208
xP11Value 0x00D2 oat 2 R Para.11 result 210
parameter 12 result bmP12Status 0x00D8 bitmask 1 R Para.12 status
1)
216
xP12Value 0x00DA oat 2 R Para.12 result 218
parameter 13 result bmP13Status 0x00E0 bitmask 1 R Para.13 status
1)
224
xP13Value 0x00E2 oat 2 R Para.13 result 226
parameter 14 result bmP14Status 0x00E8 bitmask 1 R Para.14 status
1)
232
xP14Value 0x00EA oat 2 R Para.14 result 234
parameter 15 result bmP15Status 0x00F0 bitmask 1 R Para.15 status
1)
240
xP15Value 0x00F2 oat 2 R Para.15 result 242
parameter 16 result bmP16Status 0x00F8 bitmask 1 R Para.16 status
1)
248
xP16Value 0x00FA oat 2 R Para.16 result 250
parameter 17 result bmP17Status 0x0100 bitmask 1 R Para.17 status
1)
256
xP17Value 0x0102 oat 2 R Para.17 result 258
parameter 18 result bmP18Status 0x0108 bitmask 1 R Para.18 status
1)
264
xP18Value 0x010A oat 2 R Para.18 result 266
parameter 19 result bmP19Status 0x0110 bitmask 1 R Para.19 status
1)
272
xP19Value 0x0112 oat 2 R Para.19 result 274
parameter 20 result bmP20Status 0x0118 bitmask 1 R Para.20 status
1)
280
xP20Value 0x011A oat 2 R Para.20 result 282
1)
Please refer to table Mapping of Parameter Status
