6.2 ESD protection
NOTICE
ESD (Electro Static Discharge) sensitive device. Permanent damage may occur on unconnected
devices subject to high energy electrostatic fields. Unused devices must be stored in conductive
foam or shunts. Personnel should be properly grounded prior to handling this device. The
protective foam should be discharged to the destination socket before devices are removed.
Parameter
Typical
Note
All Lines
+2kV
+1kV
Human body model (HBM)
Charged-device model (CDM)
6.3 Operating conditions
Parameter
Min
Typical
Max
Unit
Operating Voltage PWR_IN
8
12
42
V
Operating Voltage PWR_SAFE
3
5.0
5.25
V
Typical values are recommended for operation.
6.4 Ground Concept
The LRF System has to be connected to the mechanical ground of the host system via the three screws and
the supportive conducting surface around them. The LRF bench is conductive and the contact surface shall
be conductive to avoid damages to the module.
