LRF 6742 Integrator Manual
INTEGRATOR MANUAL LRF 6742 918574A
Public: 04.2023
Confidential & Proprietary  SAFRAN VECTRONIX AG – All rights reserved
Page: 22/63
6.5 Absolute maximum ratings
These are specifications for stress limits only. Functional operation of the device at these ratings or above is
not implied. Exposure to absolute maximum rating conditions for extended periods may affect reliability and
cause permanent damage to the device.
Parameter
Min
Max
Unit
PWR_IN *
-43
+43
V
PWR_SAFE
-0.3
5.5
V
RS232/RS422
-15
15
V
RS232/RS422 Interface Select
-0.3
5
V
Operating temperature
-35
70
°C
Storage temperature
-40
85
°C
* Reverse polarity protection for negative voltages only, the range of negative voltages is not operational.
6.6 Electrical characteristics
Typical values -> PWR_IN = 12V; T = 25°C (unless otherwise noted); Laboratory power source.
Max values -> PWR_IN at 12V over all temperature range.
Parameter
conditions
Min
Typical
Max
Unit
Power consumption OFF state with PWR_SAFE
5
20
mW
Power consumption Standby
Typical
100
175
mW
Power consumption normal operating
Typical
450
500
mW
Power consumption during a range measurement
Typical
2.5
3
W
Power consumption during pointing, LRF6742 LP
Typical
0.75
1
W
Inrush current peaks during start up
Typical
3
A
Inrush current peaks during measurement *1)
Typical
0.65
1
A
Input capacitance on PWR_IN
Typical
1500
uF
PWR_SAFE rise time
Typical
1.5
ms
*1) See Warning on current peaks
