8.6.7 Block Range Measurement >LM,Mb,x*<CS><CR>
This command initiates a set of x range measurements with a repetition frequency of 1 Hz.
The maximum value of the parameter x is 65535.
Ongoing block measurement can be stopped by sending the command with the parameter x=0.
Block range request command and response
Command
Inputs
Description
>LM,Mb,x*<CS><CR>
>LM,Mb,2*D2<0D>
Block range measurement with parameter x
ranges.
Example with x=2 ranges.
Response
Outputs
Description
>LM,Mb,range1,range2,range3*<CS><CR>
>LM,Mb,range1,range2,range3*<CS><CR>
>LM,Mb,v0004280,R000E301,R000E301*42<0D>
>LM,Mb,v0004276,R000E301,R000E301*47<0D>
Response of LRF with parameter x=2.
Example with parameter x=2.
Table 9: Block range measurement command
Example of a successful Block Range Measurement command transaction:
Host  LRF Module
Command frame: >LM,Mb,2*D2<0D>
LRF Module  Host
Acknowledge frame: >AC*84<0D>
Response frame: >LM,Mb, v0004280,R000E301,R000E301*62<0D>
>LM,Mb, v0004280,R000E301,R000E301*62<0D>
Prompt: <
