7 Serial interfaces
7.1 RS232
The RS232 interface uses system connector pin#19 (RS232-TX) and pin#21 (RS232-RX) with the following
parameters as default:
Parameter
Value
Baud rate
57600 Bd
Data bits
8
Start bit(s)
1
Parity
Even
Stop bit(s)
1
Signaling levels
RS232 Levels
7.2 RS422
The RS422 interface uses system connector pin#17 (RS422-TX P), pin#19 (RS422-TX N), pin#21 (RS422-RX
P) and pin#23 (RS422-RX N) with the following parameters as default:
Parameter
Value
Baud rate
57600 Bd
Data bits
8
Start bit(s)
1
Parity
Even
Stop bit(s)
1
Signaling levels
RS422 Levels
We comply with the standardized RS-422 communication.
 “P” and “N” lines have the same direction for both TX and RX
 RS-422 “IDLE” state is the transition “TX P” > “TX N”
(Or equivalently means, the “P” lines have the “IDLE” on high and transmit data on low and the “N” lines
have the “IDLE” on low and transmit data on high)
