LRF 6742 Integrator Manual
INTEGRATOR MANUAL LRF 6742 918574A
Public: 04.2023
Confidential & Proprietary  SAFRAN VECTRONIX AG – All rights reserved
Page: 36/63
8.6.5 Laser Pointer Arm Command >LM,Lp,x*<CS><CR>
This command serves as the software interlock for the laser pointer functionality.
It must be activated for allowing the laser pointer emission.
Laser pointer lock command and response
Command
Inputs
Description
>LM,Lp,x*<CS><CR>
>LM,Lp,1*DE<0D>
>LM,Lp,0*DD<0D>
Laser pointer arm request with parameter x.
Example to arm.
Example to disarm.
Response
Outputs
Description
No response expected.
Table 7: Laser pointer arm command
Examples of a laser pointer command transaction:
Host  LRF Module
Command frame: >LM,Lp,1*DE<0D>
LRF Module  Host
Acknowledge frame: >AC*84<0D>
Prompt: <
Host  LRF Module
Command frame: >LM,Rp,1*E4<0D>
LRF Module  Host
Acknowledge frame: >AC*84<0D>
Prompt: <
WARNING
Laser pointer emission is now active.
It remains active until:
- it is switched off via software command
- or if the power supply is disconnected.
Host  LRF Module
Command frame: >LM,Rp,0*E3<0D>
LRF Module  Host
Acknowledge frame: >AC*84<0D>
Prompt: <
Host  LRF Module
Command frame: >LM,Lp,0*DD<0D>
LRF Module  Host
Acknowledge frame: >AC*84<0D>
Prompt: <
