8.6.3 Continuous Low Power Mode / Alignment >LM,Tl,x*<CS><CR>
This command initiates a continuous low power laser emission at a wavelength of 1550 nm (typical).
The module provides this functionality for alignment purposes only (no range is measured).
The possible inputs for parameter x:
 x=0  OFF state
 x=1  lowest power
 x=…
 x=6  highest power
All emission levels are Class 1 eye safe and presents no risks for SWIR cameras.
Laser continuous low power mode
Command
Inputs
Description
>LM,Tl,x*<CS><CR>
>LM,Tl,1*E2<0D>
>LM,Tl,0*E1<0D>
Continuous Low Power Mode laser with parameter x power level.
Example with x=1 (lowest emitting power).
Example to switch off.
Response
Outputs
Description
--
No response expected.
Table 5: Continuous Low Power Mode command
Example of a Continuous Low Power Mode command transaction:
Host  LRF Module
Command frame: >LM,Tl,1*E2<0D>
LRF Module  Host
Acknowledge frame: >AC*84<0D>
Prompt: <
The operator performs alignment. Afterwards, the emission shall be deactivated.
Host  LRF Module
Command frame: >LM,Tl,0*E1<0D>
LRF Module  Host
Acknowledge frame: >AC*84<0D>
Prompt: <
