LRF 6742 Integrator Manual
INTEGRATOR MANUAL LRF 6742 918574A
Confidential & Proprietary SAFRAN VECTRONIX AG – All rights reserved
8.7.3 Set Range Gate Minimum >LM,Gl,x*<CS><CR>
This command sets a minimum range threshold value of x meters.
The parameter x can take values between 0 and 29999 meters.
Every range below will be filtered out after a range measurement has taken place.
This functionality applies for all range commands (except the fake range request). In addition, their
functionality remains unaltered.
Set range gate min command and response
>LM,Gl,x*<CS><CR>
>LM,Gl,500*39<0D>
Set range gate minimum with parameter x meters.
Example with x=500 meters.
Table 14: Set range gate min command
Single range request output in case of a minimum range gate
Output with applied range gate
v0018750
v0047380
v0163420
1
st
-> 187.50 m
2
nd
-> 473.80 m
3
rd
-> 1634.20 m
R000E302
v0047380
v0163420
1
st
target: Outside range gate.
2
nd
target: 473.80 m
3
rd
target: 1634.20 m
v0018750
v0047380
v0163420
1
st
-> 187.50 m
2
nd
->473.80 m
3
rd
->1634.20 m
R000E302
R000E302
v0163420
1
st
target: Outside range gate.
2
nd
target: Outside range gate.
3
rd
target: 1634.20 m
v0018750
v0163420
v0047380
1
st
->187.50 m
2
nd
->1634.20 m
3
rd
-> 473.80 m
R000E302
v0163420
R000E302
1
st
target: Outside range gate.
2
nd
target: 1634.20 m
3
rd
target: Outside range gate.
v0018750
v0163420
v0047380
1
st
->187.50 m
2
nd
->1634.20 m
3
rd
->473.80 m
R000E302
R000E302
R000E302
1
st
target: Outside range gate.
2
nd
target: Outside range gate.
3
rd
target: Outside range gate.
Table 15: Example of range output for a range gate min
Example of a set range gate min command transaction:
Host LRF Module
Command frame: >LM,Gl,500*39<0D>
LRF Module Host
Acknowledge frame: >AC*84<0D>
Prompt: <
