Sam4s ER-5200M Service Manual

9 Exploded Views and Parts List
9-10 SAM4S ER-5200 Series
9-2 Printer (STM-210)
9-2-2 Parts List(Continued)
No. Parts No. Description / Specification Q`ty Design-Location Serviceable Remark
C-18 JK72-20005A PMO-SIDE COVER: POM,BLK 1 Y
C-19 JK72-20007A PMO-GEAR REDUCTION 17_39: POM 1 Y
C-20 JK72-20008A PMO-GEAR REDUCTION 21_41: POM 1 Y
C-21 JK70-50006A SCREW-MACHINE: RH,+,2,M1.7,L2,WHITE 2 Y
C-22 JK72-20006A PMO-GEAR REDUCTION 13_43: POM 1 Y
C-23 6002-000147
SCREW TAPPING: PH,+,2,M3,L10,ZPC(YEL)
1 Y
C-24 JK68-40002A LABEL(P)-WARNING HOT: ART-PAPER 1 Y
C-25 JK70-20004A IPR-MAIN FRAME 1 Y
C-26 JK96-01233A ELA-LEVER SENSOR 1 Y
C-27 JK70-50007A SCREW-MACHINE: RH,+,2,M1.7,L8,WHITE 1 Y
C-28 JK59-40001A MOTOR ASS'Y: STM-210 1 Y
C-29 JK96-01231A ELA-P/END SENSOR 1 Y
C-30 JK70-50009A SCREW-MACHINE: RH,+,2,M2,L4,WHITE 1 Y
C-31 JK97-10004A ASS'Y TPH: STM-210 1 Y
C-32 JK39-40554A CBF SIGNAL-PRINTER FFC: 21P,120MM 1 Y
JK97-10004B ASS'Y TPH,HEAT-SINK: STM-210 1 Y
JK47-10001A TPH: ROHM 1 N
JK70-50005A TPH TAPE: 3M 1 N
C-33
JK70-20006A HEAT-SINK: ZNDC 1 N
C-34 JK70-30002A SPRING-TPH: SWP 2 Y
C-35 JK70-20005A IPR-BRACKET-REAR: SECC T1.0 1 Y
C-36 6001-000665
SCREW-MACHINE: PWH,+,2,M3,L4,ZPC(YEL)
2 Y
C-37 JK72-20002A PMO-PAPER SUPPLY: ABS+GF 20% 1 Y
C-38 JK92-01224A PBA-SUB PRT CONN BOARD: STM-210 1 Y
C-39 6002-000175
SCREW-TAPPING: PWH,+,2,M3,L8,ZPC(YEL)
1 Y
C-40 JK39-00012A CBF-HARNESS-KEY OPTION: 200mm 1 Y
C-41 JK72-20009A
PMO-COVER FRONT: HIPS(HB);NON AUTO CUTTER
1 Y
C-42 6002-000147
SCREW TAPPING: PH,+,2,M3,L10,ZPC(YEL)
1 Y
C-43 6003-000198
SCREW TAPPING: PWH,+,2,M3,L12,ZPC(YEL)
4 Y
C-44 JK72-20114A
PMO-SEPARATOR;STM-210,ABS+GF20%,BLACK
1 Y
