Sam4s ER-5200M Service Manual

9 Exploded Views and Parts List
SAM4S ER-5200 Series 9-21
9-5 Drawer
9-5-2 Parts List
9-5-2-(a) ASS’Y BILL-COIN (4B/8C, 5B/5C)
No. Code No. Description / Specification Q`ty Design-Location Serviceable Remark
JK97-20014A MEA-UNIT BILL COIN: A-TYPE, 4B8C 1 Y
a
JK97-00407A MEA-UNIT BILL COIN: A-TYPE, 5B5C 1 Y
a-1 JK72-40267A PMO-LEVER PRESS: A-TYPE,POM 4 Y
a-2 6107-000134 SPRING ES: SUS304 4 Y
a-3 JK70-10314A IPR-HOLDER LEVER: A-TYPE,T1.2,ZPC 4 Y
a-4 6002-000175 SCREW-TAPPING: PWH,+2,M3,L8,ZPC(YEL) 3 Y
a-5 6002-001078 SCREW-TAPPING: PWH,+2,M3,L5 4 Y
a-6 JK70-10304A IPR-PLATE HOLDER: A-TYPE,SBHG-1,T1.2 1 Y
a-7 JK72-40269A PMO-PANEL PARTITION: A-TYPE,HIPS,BLK 3 Y
JK72-20088A PMO-BILL COIN TILL: A-TYPE,4B8C,HIPS,BLK 1 Y
a-8
JK72-40268A PMO-BILL COIN TILL: A-TYPE,5B5C,HIPS,BLK 1 Y
a-9 JK72-20090A PMO-COIN PARTITION: A-TYPE,4B8C 6 Y
a-10 JK72-20089A PMO-COIN TILL: A-TYPE,4B8C,- 1 Y
9-5-2-(a) ASS’Y BILL-COIN (7B/8C)
No. Code No. Description / Specification Q`ty Design-Location Serviceable Remark
a JK97-01103A MEA-UNIT BILL COIN: A-TYPE, 7B8C 1 Y
a-1 6002-000175 SCREW-TAPPING: PWH,+2,M3,L8,ZPC(YEL) 3 Y
a-2 JK70-00068A IPR-HOLDER PLATE: A-TYPE,SBHG-1, T1.2 1 Y
a-3 JK72-00083A PMO-BILL PARTITION: A-TYPE,HIPS,BLK 5 Y
a-4 JK72-00082A PMO-BILL TILL: A-TYPE,HIPS,BLK 2 Y
a-5 JK72-00084A PMO-BILL COIN TILL: A-TYPE,HIPS,BLK 1 Y
9-5-2-(b) ASS’Y TRAY-TILL
No. Code No. Description / Specification Q`ty Design-Location Serviceable Remark
JK97-01073B MEA-UNIT TRAY TILL: A-TYPE,5B5C 1 N
b
JK97-01073D
MEA-UNIT TRAY TILL:
A-TYPE,4B8C,7B8C(EURO)
1 N
b-1 JK75-10389A MEC-LOCK: DRAWER 1 Y
JK70-10014A IPR-PLATE FRONT: A-TYPE,SBC-1,T1.0 1 Y
b-2
JK70-10014B IPR-PLATE FRONT: A-TYPE,4B8C,7B8C 1 Y
JK75-00025A MEA-TRAY TILL: A-TYPE,4B8C,7B8C 1 N
b-3
JK75-00025B MEA-TRAY TILL: A-TYPE,5B5C 1 N
b-4 JK73-10203A RPR-TENSION: DRAWER,SPONGE,BLK 2 N
b-5 JK75-10386A MEC-ROLLER: DRAWER,DR-10-B1/ Φ19 2 Y
b-6 6031-000549 WASHER-PLAIN: IDΦ6.5,ODΦ13, T1.0 2 Y
b-7 6003-000221 SCREW-TAPTITE: PWH,+2,M4,L8,ZPC(YEL) 1 Y
b-8 JK70-10324A IPR-SUPPORT TRAY: DRAWER,SBHG-1,T1.2 1 N
b-9 JK70-40302A ICT,SHAFT PIN: A-TYPE 1 N
b-10 6044-000124 RING-E: IDΦ3,ODΦ7, T0.6,ZPC(BLK),STSC 1 Y
b-11 6002-001042 SCREW-TAPPING: FH,+2,M3,L6 2 Y
b-12 JK70-10323A IPR-PLATE CLIP: DRAWER,SWP,T0.5 1 Y
