Sam4s ER-5200M Service Manual

9 Exploded Views and Parts List
9-22 SAM4S ER-5200 Series
9-5 Drawer
9-5-2 Parts List
9-5-2-(c) ASS’Y HOUSING
No. Code No. Description / Specification Q`ty Design-Location Serviceable Remark
JK97-01074A MEA-COVER HOUSING: A-TYPE,BASIC 1 N
c
JK97-01074B
MEA-COVER HOUSING:
A-TYPE,NONE HOLE,OPTION
1 N
JK75-00026A MEA-SUB HOUSING: A-TYPE,BASIC 1 N
c-1
JK75-00026B
MEA-SUB HOUSING:
A-TYPE,NONE HOLE,OPTION
1 N
c-2 JK75-10386A MEC-ROLLER: DRAWER,DR-10-B1/ Φ19 2 N
c-3 JK73-20207A REX-PAD DRAWER: DRAWER,NR,BLK 2 N
9-5-2-(d) ASS’Y LOCK
No. Code No. Description / Specification Q`ty Design-Location Serviceable Remark
JK97-00985A
MEA-UNIT LOCK:
A-TYPE,2-LATCH,LONG LEVER
1 Y
d
JK97-00987A
MEA-UNIT LOCK:
A-TYPE,2-LATCH,SHORT LEVER
1 Y
d-1 6002-000157 SCREW-TAPPING: PH,+2,M4,L14,ZPC(YEL) 1 Y
d-2 JK73-20210A REX-BUMPER: DRAWER,NR,BLK 1 Y
d-3 JK61-70100A SPRING-PUSH: DRAWER,FZN 1 Y
JK75-00027A
MEC-LOCK LEVER:
A-TYPE,2-LATCH,LONG LEVER
1 N
d-4
JK75-00027B
MEC-LOCK LEVER:
A-TYPE,2-LATCH,SHORT LEVER
1 N
d-5 6107-001014 SPRING-ES: Φ0.4,D4.8,L18 1 Y
d-6 JK33-10500A SOLENOID-DC: A-DRAWER 1 Y
d-7 6001-000131 SCREW-MACHINE: BH,+2,M3,L6,ZPC(YEL) 2 Y
d-8 6001-000525 SCREW-MACHINE: PH,+2,M3,L14,ZPC(YEL) 2 Y
d-9 3405-001013 SWITCH-MICRO: 125V,5A 1 Y
d-10 JK39-40301R CBF-HARNESS: 2P,150MM,BRN,1007 1 Y
d-11 6002-000161 SCREW-TAPPING: PH,+2,M4,L8,ZPC(YEL) 3 Y
9-5-2-(e) ASS’Y BOTTOM
No. Code No. Description / Specification Q`ty Design-Location Serviceable Remark
JK97-01976A MEA-UNIT BOTTOM: A-TYPE 1 N
e
JK97-01076B MEA-UNIT BOTTOM: A-TYPE,UNIVERSAL 1 N
e-1 JK70-10938A IPR-PLATE BOTTOM: A-TYPE,SBHG-1,T1.0 1 N
JK73-40200A RMO-STOPPER: DRAWER,NR,BLK 2 N
e-2
JK73-10902A RMO-STOPPER: DRAWER,NR,BLK,UNIVERSAL 2 N
e-3 JK61-40200A RMO-FOOT RUBBER: DRAWER,NR,GRAY,80HB 4 Y
e-4 6002-000234 SCREW-TAPPING: TH,+2,M4,L16,ZPC(YEL) 4 Y
e-5 6003-000267 SCREW-TAPTITE: PWH,+2,M3,L8,ZPC(YEL) 6 Y
e-6 6003-000267 SCREW-TAPTITE: PWH,+2,M3,L8,ZPC(YEL) 2 Y
e-7 JK70-10401A IPR-PLATE SPRING: DRAWER,STS304,T0.3 2 Y
e-8 6003-000267 SCREW-TAPTITE: PWH,+2,M3,L8,ZPC(YEL) 4 Y
