Sam4s ER-5200M Service Manual

10 PCB Layout and Parts List
10-2 SAM4S ER-5200 Series
10-1 Main PCB Layout
10-1-1-(b) Parts List
No Parts-No Description/Specification Q'TY Design-Location Serviceable Remark
-
JK92-01262A PBA MAIN-BOARD:ER-5200M,EUROPE,STD,2M 1
Y
-
JC68-10564A LABEL(P)-PROTECTOR:SLB-3108H,ART,-,100(S 1 U14 (FLASH ROM)
Y
-
3708-000215 CONNECTOR-FPC/FFC/PIC:20P,2.54mm,STRAIGH 1 CN7
Y
-
3708-000327 CONNECTOR-FPC/FFC/PIC:8P,2.54mm,STRAIGHT 1 CN9
Y
-
3711-000840 CONNECTOR-HEADER:BOX,30P,2R,2MM,STRAIGHT 2 CN2,CN3(PRT
Y
-
3711-001011 CONNECTOR-HEADER:BOX,5P,1R,2.5mm,STRAIGH 1 CN10 (CLERK)
Y
-
3711-001054 CONNECTOR-HEADER:BOX,6P,1R,2.5mm,STRAIGH 2 CN4,CN11
Y
-
3711-001133 CONNECTOR-HEADER:BOX,8P,1R,2.5mm,STRAIGH 1 CN14 (MODEKEY)
Y
-
3711-000041 CONNECTOR-HEADER:BOX,8P,1R,2.5mm,STRAIGH 1 CN6 (VFD)
Y
-
3711-002002 CONNECTOR-HEADER:-,22P,2R,2mm,STRAIGHT,S 1 CN12(LCD)
Y
-
3711-003359 CONNECTOR-HEADER:BOX,10P,1R,2.5mm,STRAIG 2 CN5,CN13
Y
-
2003-000502 R-METAL OXIDE(S):150ohm,5%,2W,AA,TP,4x12 1 R47
Y
-
2401-000042 C-AL:100uF,20%,16V,GP,TP,6.3x7,5 4 C27,C30,C66,C82
Y
-
2401-000131 C-AL:1000uF,20%,16V,GP,TP,10x20,5 1 C28
Y
-
2401-000962 C-AL:22uF,20%,50V,GP,TP,5x11,5 1 C88
Y
-
2401-002075 C-AL:4.7uF,20%,50V,GP,TP,5x11,5 1 C61
Y
-
0502-000234 TR-POWER:KSA1010Y,PNP,40W,TO-220,TP,100 1 Q13
Y
-
0502-000288 TR-POWER:KSD288,NPN,25W,TO-220,-,120-24 1 Q1
Y
-
3704-000255 SOCKET-IC:32P,DIP,SN,2.54mm 2 U19,U20
Y
-
1203-001752 IC-POSI.FIXED REG.:LF33CV,TO-220,3P,-,PL 1 U29
Y
-
1209-001089 IC-DETECTOR:M51953B,SIP,5P,-,PLASTIC,18V 1 U13
Y
-
2801-003263 CRYSTAL-UNIT:14.7456MHz,50ppm,28-ABR,30p 1 X1
Y
-
3002-001027 BUZZER-PIEZO:85dB,1.5V,24mA,2.048KHz,BK 1 AU1
Y
-
4302-000126 BATTERY-NICD(2ND):3.6V(1.2Vx3),60mAH,CYL 1 BAT1
Y
-
0202-000216 SOLDER-BAR:S63S-B20,S63S,350X34,SN63/PB3 1 MAIN PCB
Y
-
0202-001025 SOLDER-WIRE FLUX:KS-611,-,-,-,spray 1 MAIN PCB
Y
-
0204-000469 THINNER:#4662,-,0.795,- 1 MAIN PCB
Y
-
JK94-00060A PHANTOM AU JK92-01262A,ER-5200M,2M 1
N
-
0801-000523 IC-CMOS LOGIC:74HCT541,BUFFER/DRIVER,SOP 3 U8,U27,U30
Y
-
0801-000642 IC-CMOS LOGIC:74HC138,3-TO-8 DECODER,SOP 5 U16,U18,U21,U23,U24
Y
-
0801-000696 IC-CMOS LOGIC:74HC245,TRANSCEIVER,SOP,20 1 U28
Y
-
0801-000718 IC-CMOS LOGIC:74HC574,D FLIP-FLOP,SOP,20 1 U7
Y
-
0801-000887 IC-CMOS LOGIC:74HCT08,AND GATE,SOP,14P,1 2 U5,U25
Y
-
0801-000891 IC-CMOS LOGIC:74HCT32,OR GATE,SOP,14P,15 1 U12
Y
-
0801-001090 IC-CMOS LOGIC:74HC14,SCHIMITT INVERTER,S 2 U6,U17
Y
-
0909-000136 IC-REAL TIME CLOCK:5C15,16BIT,SOP,18P,46 1 U26
Y
-
1003-001234 IC-MOTOR DRIVER:LB1838M,SOP,14P,173MIL,S 2 U1,U3
Y
-
1106-000131 IC-SRAM:681000,128Kx8BIT,SOP,32P,525MI 2 U10,U15
Y
