Sam4s ER-5200M - Page 89

10 PCB Layout and Parts List
SAM4S ER-5200 Series 10-3
10-1 Main PCB Layout
10-1-1-(b) Parts List
No Parts-No Description/Specification Q'TY Design-Location Serviceable Remark
-
1107-001121 IC-FLASH MEMORY:29F800,1Mx8/512Kx16Bit,T 1 U14
Y
-
1202-000164 IC-VOLTAGE COMP.:393,SOP,8P,150MIL,DUAL, 1 U22
Y
-
2801-000111 CRYSTAL-SMD:32.768KHz,20ppm,28-AAW,20pF, 1 X2
Y
-
1205-001771 IC-CLOCK GENERATOR:FS781BZB,SOP,8PIN 1 U11
Y
-
0903-001155 IC-MICROCOMPUTER:30800SFP,16BIT,QFP,100P 1 U9
Y
-
0401-001003 DIODE-SWITCHING:MMBD6050LT1,70V,200mA,22 24
D5,D6,D7,D8,D9,D10,D11
D12,D13,D14,D15,D16,D17,D1
8
D19,D20,D21,D22,D23,D24,D2
5
D26,D27,D29
Y
-
0402-001189 DIODE-RECTIFIER:M4,400V,1A,SMD-2,TP 1 D2
Y
-
0404-001051 DIODE-SCHOTTKY:SK14,40V,1000MA,DO-214AA, 2 D28,D30
Y
-
0501-000457 TR-SMALL SIGNAL:MMBT2222A,NPN,350MW,SOT- 4 Q2,Q3,Q4,Q8,Q9
Y
-
0501-000457 TR-SMALL SIGNAL:MMBT2222A,NPN,350MW,SOT- 5 Q10,Q11,Q12,Q14,Q15
Y
-
2007-000026 R-CHIP:200OHM,5%,1/10W,DA,TP,2012 1 R81
Y
-
2007-000028 R-CHIP:39OHM,5%,1/10W,DA,TP,2012 10
R93,R101,R146,R147,R148
R149,R157 R158,R159,R160
Y
-
2007-000029 R-CHIP:0OHM,5%,1/10W,DA,TP,2012 2 R64,R117,C90
Y
-
2007-000290 R-CHIP:100OHM,5%,1/10W,DA,TP,2012 36
R44,R45,R46,R49,R53,R55
R59,R60,R66,R67,R68,R73
R77,R80,R82,R87,R92,R94
R96,R100,R106,R107,R108
R118,R121,R122,R128,
R51,R63,R75,R88,R105
R110,R116,R124,R125
Y
-
2007-000300 R-CHIP:10KOHM,5%,1/10W,DA,TP,2012 53
R7,R8,R9,R12,R24,R33,R35
R36,R42,R50,R56,R58,R61
R71,R72,R74,R76,R83,R84
R86,R89,R91,R95,R97,R98
R102,R103,R120,R123
R130,R131,R137,R140
R141,R145,R153,R154
R162,R165,R167,R170
R171,R172,R43,R69,R78,R90
R99,R133,R134,R144,R161
R173
Y
-
2007-000355 R-CHIP:12KOHM,5%,1/10W,DA,TP,2012 1 R113
Y
-
2007-000395 R-CHIP:150KOHM,5%,1/10W,DA,TP,2012 5 R13,R15,R18,R37,R65
Y
-
2007-000395 R-CHIP:150KOHM,5%,1/10W,DA,TP,2012 2 R127,R129
Y
-
2007-000406 R-CHIP:15KOHM,1%,1/10W,DA,TP,2012 2 R17,R34
Y
-
2007-000468 R-CHIP:1KOHM,5%,1/10W,DA,TP,2012 5 R6,R22,R26,R27,R28
Y
-
2007-000468 R-CHIP:1KOHM,5%,1/10W,DA,TP,2012 5 R57,R62,R70,R79,R115
Y
-
2007-000642 R-CHIP:270OHM,5%,1/10W,DA,TP,2012 5 R25,R30,R39,R40,R132
Y
-
2007-000686 R-CHIP:3.3KOHM,5%,1/10W,DA,TP,2012 3 R48,R54,R85
Y
-
2007-000728 R-CHIP:300OHM,5%,1/10W,DA,TP,2012 4 R29,R31,R38,R41
Y
-
2007-000872 R-CHIP:4.7KOHM,5%,1/10W,DA,TP,2012 5 R23,R32,R52,R104,R109
Y
-
2007-000872 R-CHIP:4.7KOHM,5%,1/10W,DA,TP,2012 4 R111,R112,R119,R126
Y
-
2007-001071 R-CHIP:6.8KOHM,5%,1/10W,DA,TP,2012 1 R114
Y
-
2007-000635 R-CHIP:270KOHM,5%,1/10W,DA,TP,2012 2 R14,R16
Y
