- 10 - Introduction Sam4POS Quick Start v1.1
SAP-4800II
The SAM4s SAM4POS with the SAP-4800 II All-In-One touch screen terminal is powered with an
ARM Cortex™ quad-core fan less processor to efficiently run the SAM4POS software application.
• Vivid LED Backlight for Reliability and Energy Savings
• Stylish 15" LCD with 5-Wire Resistive Touch
• ARM Cortex™-A9 Quad Core 1.0GHz Fanless Processor
• 1GB RAM
• Android Operating System
• Standard Bluetooth and WiFi
• Integrated Front-Facing Card Reader
• Two Cash Drawer Ports, Selectable 12/24-volt (12-volt default)
• Optional Integrated 2-Line by 20 Character VFD Customer Display
• Easily Wall Mountable – Standard VESA Configuration
Unbox
Carefully remove the Sam4POS terminal from the shipping container.
Remove all shipping material and protective covers.
In the case of the SAP-530, install paper into the printer:
1. Carefully open the printer cover.
2. Open the platen arm by gently pulling the yellow lever located at the front-left side of the
printer.
3. Install the 80mm thermal paper (ensure paper is being fed from the bottom of the roll).
4. Pull the leading end of the paper over the front of the printer.
5. Close the platen arm until it clicks into place.
6. Reconnect the printer cover.
CAUTION
Never touch the printer’s thermal head and platen. Avoid the thermal paper from heat. Humidity or
direct sunlight.
