- 12 - Introduction Sam4POS Quick Start v1.1
Terminal Controls & Connections
SAP-6600 Controls & Connections
Standard 3-Track
Front Facing
Magnetic Card Reader (MCR)
Power Button located
on the bottom right of
the touch panel
Standard 3-Track
Front Facing
Magnetic Card Reader (MCR)
Two v2.0 USB Ports
Connection Panel Access Cover
Cable Management Access Cover
