Technical specifications
The base forest harvester with articulated steering includes: the cab, gear box, valves, and crane on the front frame,
the engine, pumps and tanks on the rear frame.
SR 1046 PRO
Weight Weight approx. 8000-9500 kg
Maximum permissible weight (ROPS) 10000 kg
Main Dimensions
Length without crane 4.9 m
Width 2.1 – 32,3 m
Height in transport position 3.03 - 3.10m
Ground clearance 0.6 m
Engine Agcosisudiesel 44 CTA
- power 84 kW/2,200 rpm
- fuel tank 135 l
Transmission
Traction hydraulics pump 123 l / min & 420 bar
Front axle drive motor in dividing gear box 45 cc
Rear wheels with hub motors 3150 cc
Two speed ranges forward and backward 1st gear 0-4 km/h / 0-3 km/h
3rd gear 0-19 km/h
Electrically controlled flow divider valve
At the front hydraulically controlled mechanical differential lock
Tyres
Front 500/60-26.5, 540/65R28, 600/55-26.5
Rear 500/60-26.5, 540/65R28
Hydraulic system
Pump in working hydraulics 220 l/min & 210 bar
Load sensing, programmable electric joystick control (IQAN-Design)
Oil tank 110 l
Electric system
Voltage 24 V
Battery 2 x 115 Ah
Charging generator 100 A
Working lights 19
Crane Kesla H671
Operating range 7,13m
Lifting capacity (gross) 55 kNm
Crane weight 1200 kg
Harvesterhead e.g. Keto 51, 51 Victor, 51 Supreme, 55 Supreme, Kesla RH18, Nisula 400H
3-hose hydraulic system
Max. delimbing diameter 420 mm
Weight 420 – 500 kg
Brakes
At the front hydraulically & mechanically controlled drum brakes
At the rear negative multi-disc brakes
Cab Quiet safety cab (FOPS, ROPS, OPS)
Noise level 71 dB (A)
Windows Lexan Margard polycarbonate
Harvesting computer Motomit IT / PC
