Disassembly and Reassembly
Samsung Electronics4-65
No Parts Procedure Remark
9) Remove the screw what is fix with Base
Part and Drain Pan. (upper side:2EA)
10) Remove the screw what is fix with Base
Part and Drain Pan. (lower side:2EA)
11) Remove the Drain Pan completely.
