Block Diagram
13-8Samsung Electronics
13-1-8 Wall-Mounted type(Prestige)
FAN Starting
Capacitor
1. Power Input
2. Noise Filter
3. Fan Motor Driver
(SSR TYPE)
F
U
S
E
Buzzer Driver
Power Generation
1. Rectifier
2. Linear Regulator
Communication
Part
Wired Remocon
Outdoor Unit
Extra...
Sensor Input
(room, eva in/out)
LOUVER,
IONIZER
External PBA Interface
1. Main/Rmc Address
2. Operation Condition
MPU
1. Program download
interface
2. EEV
Display interface
