Disassembly and Reassembly
4-10Samsung Electronics
No Parts Procedure Remark
1 Panel
&
Filter
1) Press the Push button.
2) Separate the Front Grill
(1) Open the Grill as shown in the
picture.
(2) Separate the Grill fixing Safety Clip.
3) Filter Separation
(1) Pull back the hook at the Panel Grill
and remove the Filter.
4) Disassemble bolts and screws that are
fixed to the body of the Indoor Unit.
4-1-2 2 way cassette type
