PCB Diagram
10-9
10-1-5 Duct type(Low silhouette/Built-in)
! @
5 4
#
$ % ^
&
No. CN# COLOR FUNCTION
!
CN51 BLACK FLOAT S/W
@
CN41 WHITE ROOM/EVA-IN SENSOR
#
CN42 WHITE EVA-OUT SENSOR
$ CN32 WHITE REMOCON DC12V
% CN83 RED EXTERNAL CONTROL
^
CN62 BLUE EEV
&
CN91 WHITE DISPLAY
*
CN10 BLACK MICOM DOWNLOAD
(
CN31 RED COMM1(OUTDOOR)
)
CN33 BLUE COMM2(REMOCON)
No. CN# COLOR FUNCTION
1
CN11 RED TRANS-OUT
2
CN71 BLUE AC POWER
3 CN72 WHITE TRANS-IN
4 CN81 RED CHECK
5 CN76 YELLOW
EXTERNAL OPTION
PCB CONNECTER
6
CN77 RED HOT COIL
7
CN74 YELLOW DRAIN PUMP
8
CN75 BLACK VENTILATOR
9
CN73 WHITE FAN-MOTOR
A
B
7 6 3 2
1
)
(
*
9
8
