Block Diagram
13-4Samsung Electronics
13-1-4 Mini 4 way cassette type
Drain Pump,
Ventilator
Indoor FAN(SSR Control)
Address, Option Setting Switch
485
Communication
Sensor
(Room, Eva.
-in,out temp)
Floating Switch
Indoor Louver
Control
EEV
External Control
Signal/
External Status
Output
Display
Micom Program
Download
Wired Remocon
12V Power
Comm. Between Wired
Remocon units
