Block Diagram
Samsung Electronics13-7
13-1-7 Wall-Mounted type(Premium)
FUSE
1. Power Input
2. Noise Filter
3. Fan Motor Driver
(SSR TYPE)
Setting Part
1. Main/Rmc Address
2. Operation Condition
BUZZER
DRIVE
1. Program download interface
2. EEV DRIVE
3. LOUVER
Communication
1. Wired Remocon
2. Outdoor Unit
1. Sensor Input(room, eva in/out)
2. Display interface
3. AUTO GRILLE
MPU
Power Generation Part
1. Rectifier
2. Linear Regulator
