Samsung DVM Plus 2 Series User Manual

Electrical Parts List
Samsung Electronics6-13
■ MAIN PCB : DB93-03259B
BD71 0402-001298 DIODE-BRIDGE DF06S,600V,1A,SMD-4,TP 1 SNA
BZ61 3002-001129 BUZZER-PIEZO 85DB,-,-,2KHz,- 1 SNA
C10 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 1 SNA
C101 2401-002216 C-AL 2200uF,20%,35V,GP,TP,16x25,7.5 1 SNA
C102 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 1 SNA
C103 2401-000711 C-AL 2200uF,20%,25V,GP,TP,16x25,7.5 1 SNA
C104 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 1 SNA
C105 2401-000037 C-AL 470uF,20%,16V,GP,TP,8x11.5,5 1 SNA
C12 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 1 SNA
C201 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 1 SNA
C202 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 1 SNA
C203 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 1 SNA
C204 2203-001562 C-CER,CHIP 10nF,+80-20%,50V,Y5V,2012 1 SNA
C205 2203-001562 C-CER,CHIP 10nF,+80-20%,50V,Y5V,2012 1 SNA
C302 2203-000257 C-CER,CHIP 10nF,10%,50V,X7R,1608 1 SNA
C303 2203-000257 C-CER,CHIP 10nF,10%,50V,X7R,1608 1 SNA
C304 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 1 SNA
C305 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 1 SNA
C306 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 1 SNA
C307 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 1 SNA
C311 2203-000257 C-CER,CHIP 10nF,10%,50V,X7R,1608 1 SNA
C312 2203-000257 C-CER,CHIP 10nF,10%,50V,X7R,1608 1 SNA
C313 2203-000257 C-CER,CHIP 10nF,10%,50V,X7R,1608 1 SNA
C314 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 1 SNA
C315 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 1 SNA
C316 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 1 SNA
C401 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 1 SNA
C402 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 1 SNA
C403 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 1 SNA
C413 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 1 SNA
C441 2203-001562 C-CER,CHIP 10nF,+80-20%,50V,Y5V,2012 1 SNA
C504 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 1 SNA
C505 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 1 SNA
C506 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 1 SNA
C601 2401-002300 C-AL 47uF,20%,50V,GP,TP,6.3x11,5 1 SNA
C801 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 1 SNA
C802 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 1 SNA
C806 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 1 SNA
C807 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 1 SNA
C808 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 1 SNA
Location No. Code No. Description Q'TY SA/SNA RemarkSpecification
6-1-3 4 way cassette type

Samsung DVM Plus 2 Series Specifications

General

Brand	Samsung
Model	DVM Plus 2 Series
Category	Air Conditioner
Language	English
