Block Diagram
13-12Samsung Electronics
13-3-2 Power PCB
Power Input
Surge Protector
Linear
Regulator
For main PBA
Motor Drive
Interface
Noise Filter
AC Power Rect.
For main PBA
SMPS for
Motor Driver
+15[V]
DC LINK
Charging Part
DC LINK RECTIFIER
Capacitor
AC
Power
Rectifier
Interface with
Main PBA
Current Transducer
