Exploded Views and Parts List
5-14Samsung Electronics
No. Code No. Description Specification SA/SNA
Q'TY
AGCH095IKE
1 DB64-01143B PANEL FRONT HIPS 1 SNA
2 DB66-00757C BLADE-H SAN/GF20 4 SA
3 DB61-01871A CONNECTOR BLADE POM 8 SNA
4 DB61-01870A HOLDER BLADE ABS 8 SNA
5 DB66-00756A JOINT UNIVERSAL POM 6 SNA
6 DB66-00759A LINK MOTOR POM 2 SNA
7 DB66-00758A LINK BLADE POM 2 SNA
8 DB61-01872A BRACKET MOTOR SGCC-M 2 SNA
9 DB31-10129C MOTOR STEP GSP-24RW-045 2 SA
10 DB64-01141A INLAY PCB PC 1 SA
11 DB64-01142A BUTTON PCB ABS 1 SNA
12 DB93-02803A ASS'Y PCB DISPLAY ASS'Y 1 SA
13 - WASHER - 1 SNA
14 DB69-00947A CUSHION IN EPS 4 SNA
15 DB69-00948A CUSHION OUT EPS 4 SNA
16 DB63-01014B COVER A HIPS 1 SNA
17 DB63-01015B COVER B HIPS 1 SNA
18 DB63-01016B COVER C HIPS 2 SNA
19 DB64-01144B GRILLE AIR INLET HIPS 1 SNA
20 DB74-00002A FILTER AIR PP 1 SA
21 DB64-01145A KNOB SLIDE HIPS 2 SNA
22 DB67-00030A SPRING KNOB STS304 2 SNA
23 DB63-01036A COVER KNOB HIPS 2 SNA
24 DB70-00302A PLATE HANGER STS304 2 SNA
25 DB65-00023A CLIP WIRE ASS'Y ASS'Y 1 SNA
26 DB39-00082D CONNECT WIRE M-D ASS'Y 1 SA
27 DB39-00542C CONNECT WIRE MOTOR ASS'Y 1 SA
28 6002-001079 SCREW TAPPING TH, +, 2S, M4, L10 17 SNA
29 6002-000536 SCREW TAPPING PH, +, 2S, M4, L8 8 SNA
30 6002-000534 SCREW TAPPING PH, +, 2S, M3, L8 1 SNA
31 DB72-00298A SEAL CUSHION FLOCKED 4 SNA
■
Parts List
