Exploded Views and Parts List
5-24Samsung Electronics
■
Parts List
No. Code No. Description Specification SA/SNA
Q'TY
1 DB98-06745B ASS'Y CABI TOP DUCT TYPE 1 1 SNA
2 DB98-06744B ASS'Y CABI BASE PART DUCT TYPE 1 1 SNA
3 DB94-00599A ASS'Y DRAIN PAN DUCT TYPE 1 1 SA
4 DB96-05143B ASS'Y EVAP DUCT TYPE 1 1 SA
5 DB32-00016B THERMISTOR-ASS'Y DUCT TYPE 1 1 SA
6 DB98-05296D ASS'Y-CABI SIDE LF PART DUCT TYPE 1 1 SNA
7 DB98-05298D ASS'Y-CABI SIDE RH PART DUCT TYPE 1 1 SNA
7-1 DB64-01147A CABI SIDE RH DUCT TYPE 1 1 SA
7-2 DB63-01023A COVER CABI SIDE DUCT TYPE 1 1 SA
8 DB93-01037V ASS'Y CONTROL IN 220~240V,50Hz - 1 SA
DB93-01037J ASS'Y CONTROL IN 220~240V,50Hz 1 - SA
8-1 DB61-00451A CASE-CONTROL SGCC-M,T0.8 1 1 SNA
8-2 DB26-10065B TRANS-POWER 230V,50HZ 1 1 SA
8-3 DB65-00004H TERMINAL BLOCK-6P 6p 1 1 SA
8-4 DB65-00004C TERMINAL BLOCK-4P 4p 1 1 SA
8-5 DB93-03260A ASS'Y PCB MAIN DUCT,PCB 1 1 SA
8-6 DB61-40291B HOLDER-WIRE PP,BLK 2 2 SNA
8-7 DB63-00186A COVER-CONTROL SGCC-M,T0.8 1 1 SNA
9 DB90-01513A ASS'Y-BRACKET OUTLET DUCT TYPE 2 2 SA
10 DB94-00586K ASS'Y BLOWER DUCT TYPE - 1 SNA
DB94-00586L ASS'Y BLOWER DUCT TYPE 1 - SNA
10-1 DB31-00245A MOTOR FAN OSME-2454SAC(S331) - 1 SA
DB31-00245B MOTOR FAN OSME-1186SAC(S332) 1 - SA
10-2 DB67-00117A BLOWER LF SGCC-M 1 1 SA
10-3 DB67-00117B BLOWER-RH SGCC-M 1 1 SA
10-4 DB90-00313A ASS'Y-HOUSING DUCT TYPE 2 2 SNA
10-5 DB72-00710A BAND MOTOR SGCC-M,T1.6 4 4 SNA
10-6 DB61-00540B BRACKET-MOTOR GUIDE SGCC-M,T1.6 1 1 SNA
10-7 DB64-01148A PANEL-DUCT SGCC-M 1 1 SA
10-8 DB61-01880A BASE MOTOR SGCC-M,T2.3 1 1 SNA
AVXDLH112E
✳
AVXDLH128E
✳
AVXDLH140E
✳
