Exploded Views and Parts List
5-30Samsung Electronics
■
Parts List
No. Code No. Description Specification
SA/SNA
Q'TY
1 DB90-02014A ASS'Y CABI BASE ASS'Y
2 DB64-01324A ASS'Y CABI SIDE LF ASS'Y
3 DB90-01951A ASS'Y CABI SIDE RH ASS'Y
4 DB90-01938A ASS'Y COVER PIPE ASS'Y
5 DB90-01950A ASS'Y COVER DRAIN PUMP ABS T2.0
6 DB64-01326A CABI TOP MOTOR SGCC-M, T0.8
7 DB90-02069A ASS'Y CABI TOP EVAP ASS'Y
8 DB61-02274A PLATE HANGER SGCC-M T2.0
9 DB94-00712A ASS'Y BRACKET OUTLET ASS'Y
10 DB61-02277A BRACKET OUTLET SUB SGCC-M, T0.8
11 DB97-03385A ASS'Y CUSHION BASE ASS'Y
12 DB96-05330B ASS'Y EVAP UNIT ASS'Y
13 DB90-01978A
ASS'Y SUPPORT EVAP LF
ASS'Y
14 DB90-01946A
ASS'Y SUPPORT EVAP RH
ASS'Y
15 DB94-00768A ASS'Y PARTITION ASS'Y
16 DB61-02282A BRACKET MOTOR SGCC-M T2.0
17 DB99-00669A BAND MOTOR SINYA
18 DB31-00312A MOTOR SINYA, SSR, PID
19 DB67-00565A BLOWER
ASS'Y, ABS, TORSIONAL BUSH
20 DB90-01947A
ASS'Y CASE BLOWER UPPER
ASS'Y
21 DB90-01948A
ASS'Y CASE BLOWER BOTTOM
ASS'Y
22 DB94-00716A ASS'Y DRAIN PAN ASS'Y
23 DB93-03321A ASS'Y CONTROL IN ASS'Y
23-1 DB90-01941A ASS'Y CASE CONTROL ASS'Y
23-2 DB61-02287A CASE PCB ABS T2.5
23-3 DB63-01237A COVER CONTROL SGCC-M T0.5
23-4 DB65-00105L TERMINAL BLOCK 6P 6P, POWER
23-5 DB65-00105M TERMINAL BLOCK 6P 6P, COMMUNICATION
23-6 DB26-10070G TRANS POWER 230V, 50HZ
23-7 2301-001370 CAPACITOR 450V 1.5μF
23-8 DB93-03809A ASS'Y PCB MAIN ASS'Y
24 DB32-00142A ASS'Y THERMISTOR ASS'Y
25 DB32-00141A THERMISTOR EVAP ASS'Y
1
1
1
1
1
1
1
2
1
1
1
1
1
1
1
1
4
1
2
2
2
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
1
1
1
1
1
1
1
1
4
1
2
2
2
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
1
1
1
1
1
1
1
1
4
1
2
2
2
1
1
1
1
1
1
1
1
1
1
1
1
SA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SNA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SNA
SA
SA
SA
SA
SNA
SNA
SA
SA
SA
SA
SA
AVXDSH022E
✳
AVXDSH028E
✳
AVXDSH036E
✳
To Next Page
