Exploded Views and Parts List
5-44Samsung Electronics
■
Parts List
No. Code No. Description Specification SA/SNA
Q'TY
AVXWHH045E
✳
AVXWHH056E
✳
AVXWHH071E
✳
1 DB92-00658A ASS'Y PANEL FRONT ASS'Y 1 1 1
1-1 DB64-01263B PANEL FRONT HIPS 1 1 1
1-2 DB63-01192A FILTER-PRE PP 2 2 2
2 DB94-00653A ASS'Y TRAY DRAIN ASS'Y 1 1 1
2-1 DB63-01193A TRAY DRAIN ABS 1 1 1
2-2 DB61-02198A BLADE-H ABS 1 1 1
2-3 DB61-02197A BLADE-V PP 2 2 2
2-4 DB73-00234A RUBBER-CAP DRAIN CR 1 1 1
2-5 DB94-00062L ASS'Y DRAIN-HOSE ASS'Y 1 1 1
2-5-1 DB67-00510A DRAIN-CUFF ABS 1 1 1
2-6 DB31-00285A MOTOR STEPPING 35BYJ46-276 1 1 1
3 DB93-02960B ASS'Y DISPLAY ASS'Y 1 1 1
3-1 DB61-02196A HOLDER-DISPLAY HIPS 1 1 1
3-2 DB64-01302A WINDOW-DISPLAY HIPS 1 1 1
3-3 DB93-02806A ASS'Y PCB DISPLAY ASS'Y 1 1 1
3-4 DB93-01369A ASS'Y PCB-MODULE ASS'Y 1 1 1
4 DB63-01195A COVER TERMINAL HIPS V0 1 1 1
5 DB63-01194B COVER PCB HIPS 1 1 1
6 DB61-02194A HOLDER-EVAP ABS 1 1 1
7 DB94-00727A ASS'Y HOLDER-MOTOR ASS'Y 1 1 1
8 DB93-03660B ASS'Y CONTROL IN ASS'Y 1 1 1
9 DB96-05264A ASS'Y EVAP-TOTAL ASS'Y 1 1 -
DB96-05264B ASS'Y EVAP-TOTAL ASS'Y - - 1
10 DB67-60030A SPRING-SENSOR STS 301 1 1 1
11 DB94-00674A ASS'Y RUBBER BEARING ASS'Y 1 1 1
12 DB94-00040X ASS'Y-CROSS FAN ASS'Y 1 1 1
13 DB31-10151E MOTOR-FAN IN 220/240V, 60/50Hz 1 1 1
14 DB94-00652A ASS'Y BACK BODY ASS'Y 1 1 1
14-1 DB61-02190A BODY BACK HIPS 1 1 1
14-2 DB61-02191A BUSH-BODY LF HIPS 1 1 1
14-3 DB61-02199A BUSH-BODY RH HIPS 1 1 1
14-4 DB63-01105A COVER-IONIZER HIPS 1 1 1
14-5 DB91-00287A ASS'Y ELECTRIC-IONIZER ASS'Y 1 1 1
14-6 DB93-01383E ASS'Y CONNECTOR WIRE ASS'Y 1 1 1
15 DB61-02195A HOLDER-PIPE HIPS 1 1 1
16 DB67-00540A CAP-SCREW HIPS 3 3 3
17 DB70-00536A PLATE-HANGER SGCC-M, T0.8 1 1 1
18 DB70-00515A PLATE-CONTACT SUS 304 2 2 2
19 DB93-03016R ASS'Y REMOCON ARH-1315 1 1 1
20 DB92-00657A ASS'Y GRILLE ASS'Y 1 1 1
SA
SNA
SNA
SA
SNA
SA
SA
SA
SA
SNA
SA
SA
SNA
SNA
SNA
SA
SNA
SNA
SNA
SA
SNA
SA
SA
SNA
SA
SA
SA
SA
SNA
SNA
SNA
SNA
SA
SNA
SNA
SNA
SA
SNA
SA
SA
