Samsung Electronics
Exploded Views and Parts List
5-57
■
Parts List
Q'TY
No.
Code No. Description Specification SA/SNA
1 DB63-01225A GUARD FAN PP,ø744xH35,T3.0,1650g 1 SA
2 DB90-02119A ASS'Y COVER TOP ASS’Y 1 SNA
3 DB62-03304A BELLOW MOUTH PP,ø810xH210,T3.0,2000g 1 SA
4 DB31-00298A FAN PROPELLER AS+G/F20%,ø700xH270,2750g 1 SA
5 DB31-00330A MOTOR FAN BLDC(OUTPUT : 850W),14kg 1 SA
6 DB61-02255A BRACKET SUPPORT MOTOR SGCC-M,695x95,T2.3 2 SA
7 DB90-02143A ASS'Y FRONT BEAM UP ASS'Y 1 SNA
8 DB90-02145A ASS'Y BACK BEAM UP ASS'Y 1 SNA
9 DB90-02124A ASS'Y CABI FRONT SIDE LF ASS'Y 1 SNA
10 DB90-02125A ASS'Y CABI FRONT SIDE RH ASS'Y 1 SNA
11 DB90-02127A ASS'Y CABI BACK SIDE RH ASS'Y 1 SNA
12 DB90-02126A ASS'Y CABI BACK SIDE LF ASS'Y 1 SNA
13 DB90-02121A ASS'Y CABI FRONT UP ASS'Y 1 SNA
14 DB90-02122A ASS'Y CABI FRONT MID ASS'Y 1 SNA
15 DB90-02123A ASS'Y CABI FRONT LOW ASS'Y 1 SNA
16 DB63-01226A COVER VALVE ASS'Y 1 SA
17 DB63-01441A ASS'Y COVER PLATE ASS'Y 1 SA
18 DB90-02129A ASS'Y CABI SIDE RH ASS'Y 1 SNA
19 DB90-02128A ASS'Y CABI SIDE LF ASS'Y 1 SNA
20 DB90-02130A ASS'Y CABI BACK UP ASS'Y 1 SNA
21 DB90-02141A ASS'Y BASE COMP ASS'Y 1 SNA
22 DB61-02600A ASS'Y LEG-BASE SECC-P,970x150,T2.0 2 SNA
23 DB61-02258A BRACKET SERVICE VALVE SECC-P,350x350,T2.0 1 SNA
24 DB74-00035A SUB BKT SERVICE VALVE ASS'Y 1 SNA
25 DB90-02147A ASS'Y FRONT BEAM LOW ASS'Y 1 SNA
26 DB90-02317A ASS'Y GUARD COND BACK ASS'Y 1 SNA
27 DB90-02319A ASS'Y GUARD COND SIDE RH ASS'Y 1 SNA
28 DB90-02318A ASS'Y GUARD COND SIDE LF ASS'Y 1 SNA
29 DB96-05053A ASS'Y TUBE SUB COOLER ASS'Y 1 SA
30 DB96-04639A ASS'Y 4WAY VALVE ASS'Y 1 SA
31 DB96-04552A ASS'Y TUBE EXPANSION VALVE ASS'Y 1 SA
32 DB96-04551A ASS'Y TUBE LIQUID EEV BYPASS ASS'Y 1 SA
33 DB96-05749A ASS'Y TUBE OIL SERVICE VALVE ASS'Y 1 SA
34 DB96-04549A ASS'Y TUBE HOT-GAS BYPASS ASS'Y 1 SA
35 DB96-05747A ASS'Y TUBE OIL RETURN ASS'Y 1 SA
36 DB96-04555A ASS'Y PWM V/V ASS'Y 1 SA
37 DB96-04558A ASS'Y TUBE SUCTION ASS'Y 1 SA
38 DB96-04556A ASS'Y TUBE DISCHARGE ASS'Y 1 SA
39 DB96-04575A ASS'Y LIQUID SVC VALVE ASS'Y 1 SA
40 DB67-00562A ACCUMULATOR 8L,UNION METAL 1 SA
41 DB67-00563A OIL SEPARATOR 2L,UNION METAL 1 SA
