6-2Samsung Electronics
■ MAIN PCB : DB93-03258B(cont.)
C801 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 1 SNA
C802 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 1 SNA
C806 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 1 SNA
C807 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 1 SNA
C808 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 1 SNA
C813 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 1 SNA
C815 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 1 SNA
C816 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 1 SNA
C817 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 1 SNA
C819 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 1 SNA
C901 2203-000444 C-CER,CHIP 1nF,10%,50V,X7R,2012 1 SNA
C911 2203-001562 C-CER,CHIP 10nF,+80-20%,50V,Y5V,2012 1 SNA
C912 2203-001562 C-CER,CHIP 10nF,+80-20%,50V,Y5V,2012 1 SNA
C913 2203-001562 C-CER,CHIP 10nF,+80-20%,50V,Y5V,2012 1 SNA
C914 2203-001562 C-CER,CHIP 10nF,+80-20%,50V,Y5V,2012 1 SNA
CD11 0406-001086 DIODE-TVS ST02D-200,185/200/215V,200W,DO-214 1 SNA
CD12 0406-001086 DIODE-TVS ST02D-200,185/200/215V,200W,DO-214 1 SNA
CD312 0406-001204 DIODE-TVS SMBJ5.0CA,6.4/-/7.07V,600W,SMB 1 SNA
CD334 0406-001204 DIODE-TVS SMBJ5.0CA,6.4/-/7.07V,600W,SMB 1 SNA
CN10 3711-005716
HEADER-BOARD TO CABLE BOX,10P,1R,2mm,STRAIGHT,SN,BLK 1 SNA
CN31 3711-000177
HEADER-BOARD TO CABLE 1WALL,2P,1R,3.96mm,STRAIGHT,SN,RED 1 SNA
CN32 3711-000178
HEADER-BOARD TO CABLE 1WALL,2P,1R,3.96mm,STRAIGHT,SN,WHT 1 SNA
CN33 3711-000176
HEADER-BOARD TO CABLE
1WALL,2P,1R,3.96mm,STRAIGHT,SN,BLU 1 SNA
CN41 3711-004379
HEADER-BOARD TO CABLE BOX,4P,1R,2mm,STRAIGHT,SN,NTR 1 SNA
CN42 3711-003942
HEADER-BOARD TO CABLE BOX,2P,1R,2mm,STRAIGHT,SN,WHT 1 SNA
CN44 3711-000879
HEADER-BOARD TO CABLE BOX,3P,1R,2.5mm,STRAIGHT,SN,BLU 1 SNA
CN51 3711-000794
HEADER-BOARD TO CABLE
BOX,2P,1R,2.5mm,STRAIGHT,SN 1 SNA
CN60 3711-004236
HEADER-BOARD TO CABLE BOX,6P,1R,2mm,STRAIGHT,SN 1 SNA
CN62 3711-001001 CONNECTOR-HEADER BOX,5P,1R,2.5mm,STRAIGHT,SN,BLU 1 SNA
CN71 3711-003404
HEADER-BOARD TO CABLE 1WALL,2P,1R,7.92mm,STRAIGHT,SN,BLU 1 SNA
CN73 3711-000262
HEADER-BOARD TO CABLE 1WALL,3P,1R,7.92mm,STRAIGHT,SN,WHT 1 SNA
CN74 3711-000203
HEADER-BOARD TO CABLE 1WALL,2P/3P,1R,7.92mm,STRAIGHT,SN,WHT 1 SNA
CN75 3711-003405
HEADER-BOARD TO CABLE
1WALL,2P,1R,7.92mm,STRAIGHT,SN,BLK 1 SNA
CN81 3711-000939
HEADER-BOARD TO CABLE
BOX,4P,1R,2.5mm,STRAIGHT,SN 1 SNA
CN83 3711-000796
HEADER-BOARD TO CABLE BOX,2P,1R,2.5mm,STRAIGHT,SN,RED 1 SNA
CN91 3711-004712
HEADER-BOARD TO CABLE BOX,9P,1R,2mm,STRAIGHT,SN,WHT 1 SNA
CR71 2301-001094 C-FILM,LEAD-PPF 1.5uF,10%,450V,BK,38x18x30,33m 1 SNA
Location No. Code No. Description Q'TY SA/SNA RemarkSpecification
1 way cassette type(cont.)
