Electrical Parts List
6-8Samsung Electronics
■ MAIN PCB : DB93-03297B(cont.)
C815 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 1 SNA
C816 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 1 SNA
C817 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 1 SNA
C819 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 1 SNA
C901 2203-000444 C-CER,CHIP 1nF,10%,50V,X7R,2012 1 SNA
C902 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 1 SNA
C911 2203-001562 C-CER,CHIP 10nF,+80-20%,50V,Y5V,2012 1 SNA
C912 2203-001562 C-CER,CHIP 10nF,+80-20%,50V,Y5V,2012 1 SNA
C913 2203-001562 C-CER,CHIP 10nF,+80-20%,50V,Y5V,2012 1 SNA
C917 2203-001562 C-CER,CHIP 10nF,+80-20%,50V,Y5V,2012 1 SNA
C918 2203-000192 C-CER,CHIP 100nF,+80-20%,50V,Y5V,2012 1 SNA
CD312 0406-001204 DIODE-TVS SMBJ5.0CA,6.4/-/7.07V,600W,SMB 1 SNA
CD334 0406-001204 DIODE-TVS SMBJ5.0CA,6.4/-/7.07V,600W,SMB 1 SNA
CN10 3711-005716
HEADER-BOARD TO CABLE
BOX,10P,1R,2mm,STRAIGHT,SN,BLK 1 SNA
CN11 3711-000880
HEADER-BOARD TO CABLE BOX,3P,1R,2.5mm,STRAIGHT,SN,RED 1 SNA
CN31 3711-000177
HEADER-BOARD TO CABLE 1WALL,2P,1R,3.96mm,STRAIGHT,SN,RED 1 SNA
CN32 3711-000178
HEADER-BOARD TO CABLE 1WALL,2P,1R,3.96mm,STRAIGHT,SN,WHT 1 SNA
CN33 3711-000176
HEADER-BOARD TO CABLE 1WALL,2P,1R,3.96mm,STRAIGHT,SN,BLU 1 SNA
CN41 3711-000940
HEADER-BOARD TO CABLE BOX,4P,1R,2.5mm,STRAIGHT,SN,WHT 1 SNA
CN42 3711-000015
HEADER-BOARD TO CABLE BOX,2P,1R,2.5mm,STRAIGHT,SN,WHT 1 SNA
CN44 3711-000879
HEADER-BOARD TO CABLE
BOX,3P,1R,2.5mm,STRAIGHT,SN,BLU 1 SNA
CN45 3711-003407
HEADER-BOARD TO CABLE 1WALL,2P,1R,7.92mm,STRAIGHT,SN,RED 1 SNA
CN46 3711-003407
HEADER-BOARD TO CABLE
1WALL,2P,1R,7.92mm,STRAIGHT,SN,RED 1 SNA
CN51 3711-000794
HEADER-BOARD TO CABLE BOX,2P,1R,2.5mm,STRAIGHT,SN 1 SNA
CN52 3711-000024
HEADER-BOARD TO CABLE BOX,3P,1R,2.5mm,STRAIGHT,SN,WHT 1 SNA
CN60 3711-003844
HEADER-BOARD TO CABLE BOX,12P,1R,2mm,STRAIGHT,SN 1 SNA
CN61 3711-002001
HEADER-BOARD TO CABLE BOX,20P,2R,2mm,STRAIGHT,SN,BLK 1 SNA
CN62 3711-001001 CONNECTOR-HEADER BOX,5P,1R,2.5mm,STRAIGHT,SN,BLU 1 SNA
CN71 3711-003404
HEADER-BOARD TO CABLE
1WALL,2P,1R,7.92mm,STRAIGHT,SN,BLU 1 SNA
CN72 3711-000203
HEADER-BOARD TO CABLE 1WALL,2P/3P,1R,7.92mm,STRAIGHT,SN,WHT 1 SNA
CN73 3711-000262
HEADER-BOARD TO CABLE 1WALL,3P,1R,7.92mm,STRAIGHT,SN,WHT 1 SNA
CN74 3711-003406
HEADER-BOARD TO CABLE 1WALL,2P,1R,7.92mm,STRAIGHT,SN,YEL 1 SNA
CN75 3711-003405
HEADER-BOARD TO CABLE 1WALL,2P,1R,7.92mm,STRAIGHT,SN,BLK 1 SNA
CN78 3711-000260
HEADER-BOARD TO CABLE 1WALL,3P,1R,7.92mm,STRAIGHT,SN,BLU 1 SNA
CN91 3711-004712
HEADER-BOARD TO CABLE
BOX,9P,1R,2mm,STRAIGHT,SN,WHT 1 SNA
D105 0402-000137 DIODE-RECTIFIER 1N4007,1KV,1A,DO-41,TP 1 SNA
F701 3602-001012 FUSE-BLOCK 500V,-,100m 1 SNA
F701_1 3601-000263 FUSE-CARTRIDGE 250V,3.15A,TIME-LAG,GLASS,5x20mm 1 SNA
F702 3601-001308 FUSE 250V,1.6A,TIME-LAG,PLASTIC,8.4x7.6mm 1 SNA
FT71 DB27-00019A COIL CHOKE SSC1905200B,Line Filter,20mH,+50%,-30%,-, 1 SNA
0.3ohm,2.5A,20x28 mm,-,13x18,-,-,-,-25
Location No. Code No. Description Q'TY SA/SNA RemarkSpecification
2 way cassette type(cont.)
