Electrical Parts List
6-18Samsung Electronics
■ MAIN PCB : DB93-03259B(cont.)
RY78 3501-001264 RELAY-POWER 12VDC,200mW,5000mA,1FormA,10mS,10mS 1 SNA
SCREW 6002-000630 SCREW-TAPPING PH,+,-,2S,M3,L8,ZPC(YEL),SWRCH18A,- 1 SNA
SW01 3406-001098 SWITCH-ROTARY 240V AC,25A,6P(10C),L14mm 1 SNA
SW02 3406-001098 SWITCH-ROTARY 240V AC,25A,6P(10C),L14mm 1 SNA
SW03 DB34-00009A SWITCH-DIGITAL PT65 103,ROTARY DIP,-,DC24V Max,0.4VA, 1 SNA
50mOhm Max,-,BULK,10mmx10mm,straight,-,-,-
SW04 DB34-00009A SWITCH-DIGITAL PT65 103,ROTARY DIP,-,DC24V Max,0.4VA, 1 SNA
50mOhm Max,-,BULK,10mmx10mm,straight,-,-,-
SW05 3407-000121 SWITCH-DIP 24V,300mA,SLIDE,STANDARD 1 SNA
SW06 3407-000121 SWITCH-DIP 24V,300mA,SLIDE,STANDARD 1 SNA
SW07 3407-000121 SWITCH-DIP 24V,300mA,SLIDE,STANDARD 1 SNA
VA71 1405-000154 VARISTOR 460Vdc,2500A,17.5x7.5mm,TP 1 SNA
X301 2802-001179 RESONATOR-CERAMIC 4MHz,0.5%,BK,8X3X5.5mm 1 SNA
X701 2301-001220 C-FILM,LEAD-PPF 100nF,10%,275V,BK,18x6x12,15 1 SNA
X702 2301-001220 C-FILM,LEAD-PPF 100nF,10%,275V,BK,18x6x12,15 1 SNA
Location No. Code No. Description Q'TY SA/SNA RemarkSpecification
