Electrical Parts List
6-20Samsung Electronics
■ MAIN PCB : DB93-04122A(cont.)
F701_1 3601-000170 FUSE-CARTRIDGE 250V,1.6A,TIME-LAG,GLASS,5x20mm 1 SNA
F702 3601-001209 FUSE 250V,1A,TIME-LAG,-,8.5x8mm 1 SNA
FT71 DB27-00019A FILTER-EMI AC LINE
SSC1905200B,Line Filter,20mH,+50%,-30%,
1 SNA
-,0.3ohm,2.5A,20x28 mm,-,13x18,-,-,-,-25
HEAT-SINK DB62-03581A HEAT SINK
DPM,A6063,1.3,15,15,WHT,-,HEIGHT : 25.5
1 SNA
IC01 1203-002545 IC-PWM CONTROLLER 266,DIP,8P,300MIL,PLASTIC,-0.3/700V,-, 1 SNA
-40TO+150C,560mA,-,ST
IC02 1203-000274
IC-POSI. FIXED REGULATOR
7805,TO-220,3P,-,PLASTIC,4.8/5 1 SNA
IC03 1203-003334 IC-RESET S-801,SOT-23,5P,2.9x1.6mm,PLASTIC, 1 SNA
3.716/4.284V,256mW,-,2.5mA,-,TP
IC04 DB09-00395A IC MICOM MB90F823,-,80 P,5 V,24 MHz,
STM-0519-OS,-,24,16,QFP,QFP, 1 SNA
14x20 mm,16,-40~85
IC05~IC09 0506-000175 TR-ARRAY 2003,NPN,7,1W,SOP-16,ST,1000 5 SNA
IC18,IC19 1006-001325 IC-BUS TRANSCEIVER 1487,SO,8P,4.9x3.8 mm,SINGLE,ST, 2 SNA
PLASTIC,5V,-40to+85CC,520mW,1,1,
1.5/5.25V,-
IC20 0801-000393 IC-CMOS LOGIC 74HC86,OR GATE,SOP,14P,150MIL, 1 SNA
QUAD,ST,-,2.0/6.0V,0.26V,-40to+85C,
180mW,4.2V,1uA,
IC51 1103-001175 IC-EEPROM 93LC56,128x16,SOP,8P,5x4mm,2.5/6.0V, 1 SNA
-40to+85C
LED11 0601-001373 LED ROUND,RED,3mm,630nm 1 SNA
LED12 0601-001375 LED ROUND,GRN,3mm,570nm,3.8x5.3mm 1 SNA
LED13 0601-001377 LED ROUND,YEL,3mm,585nm,3.8x5.3mm 1 SNA
NTC1 1404-001274 THERMISTOR-NTC 22OHM,1.4A,3100K,9.5MW/C,-,7.0,- 1 SNA
PC01 0604-001038 PHOTO-COUPLER TR,130-260%,200mW,DIP-4,ST 1 SNA
PC02 0604-001003 PHOTO-COUPLER TR,50-150%,200mW,DIP-4,ST 1 SNA
PCB DB41-00408A PCB
MINI 4WAY,FR-4,2,00,1.6,70 x 230,-,3,MAIN,-
1 SNA
Q201,Q441,Q601,Q603 0501-000534 TR-SMALL SIGNAL 2SC2412K,NPN,200mW,SOT-23,TP,1 4 SNA
Q602 0501-002296 TR-SMALL SIGNAL
mmST2907A,PNP,200mW,SMT3,TP,100-300
1 SNA
Q901,Q902,Q904~Q910 0504-000001 TR-DIGITAL
DTA114EKA,PNP,200mW,10K/10K,SOT-23,TP
9 SNA
R10~R12 2007-000023 R-CHIP 120ohm,5%,1/8W,TP,2012 3 SNA
R101 2007-000290 R-CHIP 100ohm,5%,1/8W,TP,2012 1 SNA
R102 2007-000493 R-CHIP 2.2Kohm,5%,1/8W,TP,2012 1 SNA
R103,R104 2002-001104 R-COMPOSITION 12Mohm,5%,1/2W,AA,TP,3.4x9mm 2 SNA
R105,R607,R608 2007-000931 R-CHIP 470ohm,5%,1/8W,TP,2012 3 SNA
R201,R211,R350,R441, 2007-000468 R-CHIP 1Kohm,5%,1/8W,TP,2012 10 SNA
R443,R602,R602,R604,
R610,R902
R202~R208,R701 2007-000944 R-CHIP 47Kohm,5%,1/4W,TP,3216 8 SNA
Location No. Code No. Description Q'TY SA/SNA RemarkSpecification
Mini 4 way cassete type(cont.)
