Electrical Parts List
Samsung Electronics6-27
■ MAIN PCB : DB93-03619B(cont.)
RY76 3501-001163 RELAY-MINIATURE 12VDC,200mW,5000mA,1FormA,10mS,5mS 1 SNA
RY77 3501-001163 RELAY-MINIATURE 12VDC,200mW,5000mA,1FormA,10mS,5mS 1 SNA
RY78 3501-001163 RELAY-MINIATURE 12VDC,200mW,5000mA,1FormA,10mS,5mS 1 SNA
SCREW 6002-000630 SCREW-TAPPING PH,+,-,2S,M3,L8,ZPC(YEL),SWRCH18A,- 2 SNA
SW01 3406-001098 SWITCH-ROTARY 240V AC,25A,6P(10C),L14mm 1 SNA
SW02 3406-001098 SWITCH-ROTARY 240V AC,25A,6P(10C),L14mm 1 SNA
SW03 DB34-00009A SWITCH-DIGITAL PT65 103,ROTARY DIP,-,DC24V Max,0.4VA, 1 SA
50mOhm Max,-,BULK,10mmx10mm,straight,-,-,-
SW04 DB34-00009A SWITCH-DIGITAL PT65 103,ROTARY DIP,-,DC24V Max,0.4VA, 1 SA
50mOhm Max,-,BULK,10mmx10mm,straight,-,-,-
SW05 3407-000121 SWITCH-DIP 24V,300mA,SLIDE,STANDARD 1 SNA
SW06 3407-000121 SWITCH-DIP 24V,300mA,SLIDE,STANDARD 1 SNA
SW07 3407-000121 SWITCH-DIP 24V,300mA,SLIDE,STANDARD 1 SNA
VA71 1405-000154 VARISTOR 460Vdc,2500A,17.5x7.5mm,TP 1 SNA
VA75 1405-000154 VARISTOR 460Vdc,2500A,17.5x7.5mm,TP 1 SNA
X301 2802-001179 RESONATOR-CERAMIC 4MHz,0.5%,BK,8x3x5.5mm 1 SNA
X701 2301-001220 C-FILM,LEAD-PPF 100nF,10%,275V,BK,18x6x12,15 1 SNA
X702 2301-001220 C-FILM,LEAD-PPF 100nF,10%,275V,BK,18x6x12,15 1 SNA
Location No. Code No. Description Q'TY SA/SNA RemarkSpecification
