3.DisassemblyandReassembly
3.DisassemblyandReassembly
3.1.OverallDisassemblyandReassembly
CAUTION
•Becarefultofollowthedisassemblysequencedescribedinthemanual.Otherwise,theproductmaybedamaged.
•BesuretocarefullyreadandunderstandthesafetyinstructionsbeforeperforminganyworkastheICchipson
thePCBarevulnerabletostaticelectricity.
•Inordertoassemblereversetheorderofdisassembly.
DescriptionDescriptionPhoto
1.Unfasten4screwsontherearside.
:BH,+,B,M3,L10,ZPC(BLK),SWRCH18A
2.SlidetheCover-Topbacktoremove.
PullsidecoverandliftupCover-Top.
CAUTION
Becarefulnottomakeanyscratchesasyouremovethem.
Copyright©1995-2012SAMSUNG.Allrightsreserved.3-1
