Samsung HT-E6730W - Pin Connection

5.PCBDiagram
5.4.1.PinConnection
1)WCN1
WiModule
PinNo.Signal
1DGND
2DGND
3USB+
4USB-
5USBPWR
2)BCN1
BlutoothModule
PinNo.Signal
1VT_IN_FL
2GND
3VT_IN_FR
4VT_HT
512V
3)CN3
DeckPickupconnector
PinNo.Signal
1BD_HFM
2GND
3GND
4GND
5T+
6F1_
7F1-
8F2+
9F2-
10T-
11GND
12A
13B
14C
15D
16E
17F
18G
19H
20BDRF-
PinNo.Signal
21BDRF+
22VREF_1.65V
23VCC_5V
24VREF_2.1V
25DVD_PD_FSW
26BD_PD_FSW
27PU_SEL
28BDMPD
29DVD_VR
30DVD_MPD
31CD_VR
32GND
33DVDLD
34BDLD
35CDLD
36GND
37M_A-
38M_A
39M_B-
40M_B-
4)CN2
DeckMotorconnector
PinNo.Signal
1DISCIN
2LDO+
3LDO-
4CLOSE
5OPEN
6GND
7NC
8SLO1+
9SLO1-
10SLO2-
11SLO2+
12CM
13U
14V
15W
5)CN22
TouchKey/VFDInterface
PinNo.Signal
1ST3.4V
2T_RST
3GND
4VFD_CLK
5VFD_DA T A
6VR_CE
7GND
812V
912V
10D3.3V
11REMOT
12GND
13TC_DATA
14TC_CLK
15GND
