Samsung HT-E6730W - Pin Connection

5.PCBDiagram
5.6.1.PinConnection
1)VCN1
USB/ASCInterface,VTAudio
PinNo.Signal
1USB5V
2USB5V
3USB-
4USB+
5DGND
6ASCMICIN
7DGND
8ASC_Sen
9R12V
10R12V
11FGND
12VT_IN_FL
13FGND
14VT_IN_FR
15FGND
16VT_OUT_FL
17FNGD
18VT_OUT_FR
19FGND
20VT_CTL
2)VCN2
VTAudio
PinNo.Signal
1VT_IN_FL
2GND
3VT_IN_FR
4VT_HT
512V
6NC
7190V
8190V
9NC
10GND
11GND
12VT_OUT_FL
13GND
14VT_OUT_FR
5-12Copyright©1995-2012SAMSUNG.Allrightsreserved.
