Samsung mini DVM Series User Manual

Disassembly and Reassembly
Samsung Electronics4-13
No Parts Procedure Remark
3 Heat Exchanger
1) Remove screws from the Connection Pipe
cover.
2) Separate the Connection Pipe cover from
the Indoor Unit.
3) Remove 16 fixing screws from the Drain
Pan.
4) Separate the Drain Pan from the Indoor
Unit.
