Samsung mini DVM Series User Manual

Disassembly and Reassembly
4-36Samsung Electronics
No Parts Procedure Remark
2) Disassemble indicating screws.
3) Detach the Sensor Holder from the
Ass'y Fan case.
4) Detach from Ass'y Control in the
capacitor connection wire between the
Motor-Fan in and Housing Connector.
5) Detach the Ass'y Blower and Duct from
the set.
